Simplicity Colt ZT2148T Parts Manual page 29

Engine & PTO Group
REF NO. PART NO.
1A 22888
1B 22889
* 21144-1
* 21178-3
* *
* *
2 25011-6
3 25013-8
4 3847134
5 25057
6 25096
7 25165
8 43636
9 25156
10 44853
11 45475
12 23231
13 50407-28
14 47075
15 47033
16 25126
17 25010-6
18 3847346
19A 22952**
19B 22952
20 25155
21 25127
22 21466
23 21372
24 21392
25 21500
26 50857-13
27 50862-12
Footnotes:
* See your local Kohler engine dealer for service parts
** Silver version not available for replacement parts. If muffler is replaced, remove heat shield (ref 18)
The above parts group applies to the following Model Nos.:
ZT2148T
ZT2348T
ZT2352T
TP 400-7090-03-CT-D
QTY. DESCRIPTION
1 ENGINE, 21HP Kohler
1 ENGINE, 23HP Kohler
1 OIL FILTER
1 FUEL FILTER
1 PRE-CLEANER (4508301)
1 AIR FILTER (4508302)
2 CAPSCREW, Hex Hd, 5/16-18 x 3/4
3 CAPSCREW, Hex Hd, 3/8-16 x 1
1 CLUTCH ANCHOR
2 NUT, Hex, Nylon Lock, 5/16-18
3 NUT, Hex, Nylon Lock, 3/8-16
3 WASHER, Fender, 3/8
1 CLUTCH ANCHOR PAD
1 WASHER, 3/8
1 CRANKSHAFT BOLT, 7/16 x 2
1 SPACER, .45 x 1.88 x .38
1 ELECTRIC CLUTCH
1 KEY, 1/4 Sq. x 3-1/2
1 CRANKSHAFT PULLEY
1 SPACER, 1.13 x 1.75 x 1.03
3 NUT, Hex, Serrated Flange, 1/4-20
3 CAPSCREW, Hex Hd, 1/4-20 x 3/4
1 MUFFLER HEAT SHIELD (for use with silver version muffler only)
1 MUFFLER (silver version, S/N 101-123, both models)
1 MUFFLER (black version, S/N 124 & up, both models)
1 WASHER, 5/16
1 NUT, Hex, Serrated Flange, 5/16-18
1 CAP, 3/8NPT
2 FITTING, 3/8NPT - 1/2 Str.
2 HOSE CLAMP
1 CLAMP, Vinyl
1 HOSE, 13"
1 WIRE LOOM, 12"
23
