Simplicity Colt ZT2148T Parts Manual page 37

Hydraulic Group
REF NO. PART NO.
1 22723
2 21356
3 21357
4 22720
5 22719
6 50848-7.5
7 22718
8 22716
9 22717
10 22713
11 50860-13.75
12 22714
13 22712
14 22715
15 50860-6.75
16 22571
* 22571-2
17 50860-29
18 21392
19 22708
20 22705
21 3847108
22 50860-20
23 22633
24 22710
25 22711
26 50848-16.5
27 21164
28 22707
29 22709
30 22634
31 22975L
32 22042-2
33 22042-3
34 22975R
Footnotes:
The above parts group applies to the following Model Nos.:
ZT2148T (S/N: 338 & below)
ZT2352T (S/N: 363 & below)
TP 400-7090-01-CT-D
QTY. DESCRIPTION
1 FITTING, 1/2" NPT, 90 Deg.
1 FILTER HEAD
1 FILTER
1 FITTING, 1/2" NPT, 45 Deg.
2 FITTING, Hydraulic, Straight Swivel
1 HOSE, Hydraulic, 7-1/2"
1 FITTING, Tee
2 ADAPTER, Tee
2 NUT, Adapter
3 FITTING, Hydraulic, Straight Swivel
1 HOSE, Hydraulic, 13-3/4"
2 FITTING, Hydraulic, 45 Deg. Swivel
4 FITTING, Hydraulic, O-Ring, 90 Deg.
1 FITTING, Hydraulic, 90 Deg. Swivel
1 HOSE, Hydraulic, 6-3/4"
2 HYDRAULIC PUMP w/ FAN
2 Fan
1 HOSE, Hydraulic, 29"
2 HOSE CLAMP, #6
2 FITTING, 1/4" NPT, 90 Deg.
1 BREATHER
1 HYDRAULIC RESERVOIR
1 HOSE, Hydraulic, 20"
4 FITTING, Hydraulic, O-Ring Adapter
3 HYDRAULIC HOSE ASSEMBLY, 25"
1 HYDRAULIC HOSE ASSEMBLY, 21"
1 HOSE, Hydraulic, 16-1/2"
1 HOSE CLAMP, #10
1 FITTING, 1/2" NPT, 90 Deg.
3 FITTING, Hydraulic, O-RIng, 45 Deg.
1 FITTING, Hydraulic, O-Ring Adapter
1 HYDRAULIC WHEEL MOTOR-LEFT, Complete (includes Ref 32 & 33)
2 KEY
2 NUT & COTTER PIN
1 HYDRAULIC WHEEL MOTOR-RIGHT, Complete (includes Ref 32 & 33)
31
