Simplicity Colt ZT2148T Parts Manual page 39

Hydraulic Group
REF NO. PART NO.
1 21233
2 21356
3 21357
4 22720
5 22719
6 50848-7.5
7 22718
8 22716
9 22717
10 22713
11 50860-13.75
12 22714
13 22712
14 22715
15 50860-6.75
16 22571
* 22571-2
17 50860-16.5
18 21392
19 22920
20 50860-6
21 50860-17.5
22 23118
23 23120
24 21468
25 48111
26 23121
27 23119
28 21164
29 50848-18
30 22633
31 22711
32 22710
33 22709
34 22634
35A 22975L
35B 22974L
36 22042-2
37 22042-3
38A 22975R
38B 22974R
Footnotes:
The above parts group applies to the following Model Nos.:
ZT2148T (S/N: 339 & above)
ZT2348T
ZT2352T (S/N: 364 & above)
TP 400-7090-01-CT-D
QTY. DESCRIPTION
1 FITTING, 1/2" NPT, 90 Deg.
1 FILTER HEAD
1 FILTER
1 FITTING, 1/2" NPT, 45 Deg.
2 FITTING, Hydraulic, Straight Swivel
1 HOSE, Hydraulic, 7-1/2"
1 FITTING, Tee
2 ADAPTER, Tee
2 NUT, Adapter
3 FITTING, Hydraulic, Straight Swivel
1 HOSE, Hydraulic, 13-3/4"
2 FITTING, Hydraulic, 45 Deg. Swivel
4 FITTING, Hydraulic, O-Ring, 90 Deg.
1 FITTING, Hydraulic, 90 Deg. Swivel
1 HOSE, Hydraulic, 6-3/4"
2 HYDRAULIC PUMP w/ FAN
2 Fan
1 HOSE, Hydraulic, 16-1/2"
4 HOSE CLAMP, #6
1 FITTING, TEE, 3/8"
1 HOSE, Hydraulic, 6"
1 HOSE, Hydraulic, 17-1/2"
1 FITTING, Elbow, 3/8"
1 GROMMET
1 CAP
1 HYDRAULIC OIL RESERVOIR, Complete (includes Ref. No. 22, 23, 26 & 27)
1 GROMMET
1 FITTING, Elbow, 5/8"
2 HOSE CLAMP, #10
1 HOSE, Hydraulic, 18"
4 FITTING, Hydraulic, O-Ring Adapter
2 HYDRAULIC HOSE ASSEMBLY, 21"
2 HYDRAULIC HOSE ASSEMBLY, 25"
2 FITTING, Hydraulic, O-RIng, 45 Deg.
2 FITTING, Hydraulic, O-Ring Adapter
1 HYDRAULIC WHEEL MOTOR-LEFT, Complete (includes Ref No. 36 & 37)
(ZT2148T - S/N: 678 & below)
(ZT2352T - S/N: 835 & below)
1 HYDRAULIC WHEEL MOTOR-LEFT, Complete (includes Ref No. 36 & 37)
(ZT2148T - S/N: 679 & above)
(ZT2348T - all)
(ZT2352T - S/N: 836 & above)
2 KEY
2 NUT & COTTER PIN
1 HYDRAULIC WHEEL MOTOR-RIGHT, Complete (includes Ref No. 36 & 37)
(ZT2148T - S/N: 678 & below)
(ZT2352T - S/N: 835 & below)
1 HYDRAULIC WHEEL MOTOR-RIGHT, Complete (includes Ref No. 36 & 37)
(ZT2148T - S/N: 679 & above)
(ZT2348T - all)
(ZT2352T - S/N: 836 & above)
33
