Decals - Brand, Model, Safety & Operation - Simplicity Colt ZT2148T Parts Manual

Decals - Brand, Model, Safety & Operation
1
2
3
4
5
6
7
8
9
10
11
12
The above parts group applies to the following Model Nos.:
ZT2148T
ZT2348T
ZT2352T
© Copyright 2004 Ferris Industries. All Rights Reserved.
Key Charge PTO
Auxiliary
Switch Circuit Clutch
20A
20A 20A 20A
46503
47138
WARNING
(old version)
BEWARE OF
POWER DRIVEN PARTS
(new version)
GREASE
DAILY
21036
48"
52"
OPERATION
To Start Engine:
Seat must be occupied, PTO
Switch OFF, Parking Brake ON
and both control handles are
locked in Neutral.
To Stop Engine:
Engage Parking Brake, Throttle at
half to full, turn Ignition Switch Off.
Before Leaving Machine:
Turn PTO switch off, shut off engine,
remove key, and set Parking
Brake
GROUND SPEED AND
STEERING LEVERS
Right lever controls speed
and direction of right drive
wheel. Notch is neutral
lock.
Left lever controls speed and
direction of left drive wheel.
Notch is neutral lock.
Steer by slowing the lever in
the direction of the turn.
PARKING BRAKE
LEVER
Pull to set Parking Brake.
Push to release Parking
Brake.
DECK LIFT PEDAL
Push to raise deck.
CUTTING HEIGHT
ADJUSTMENT PIN
NOTE: Decals are NOT shown to scale.
58
To Operate PTO Clutch:
Operator must be in seat.
Pull up to Engage.
Push down to Disengage.
When Operator Leaves Seat:
Engine will shut off if PTO is on.
Engine will shut off of Parking Brake
is off.
Engine will shut off if both control
levers are not locked in neutral.
DO NOT TOW!
Damage may result to
Hydrostatic Transmission.
TP 400-7090-01-CT-D
13
14
15
16
17
18
19
20
21
22
23
24
25
26
