Simplicity Colt ZT2148T Parts Manual page 51

Tire & Wheel Group
REF NO. PART NO.
1 22631S
2 22029-1
3 22631S-1
4 22631S-2
5 22631S-3
6 47103
7 25017-60
8 25056
9 22646S
10 22646S-1
11 22646S-2
12 22215
Footnotes:
The above parts group applies to the following Model Nos.:
ZT2148T
ZT2348T
ZT2352T
TP 400-7090-01-CT-D
QTY. DESCRIPTION
2 WHEEL & TIRE ASSEMBLY, Front, 13 x 5.0 x 6, Complete (includes Ref 2-5)
2 TIRE, Front, 13 x 5.0 x 6
2 WHEEL ASSEMBLY, Front, for 13 x 5.0 x 6 Tire, Complete (includes Ref 4 & 5)
4 BEARING, Taper Roller (2 per wheel)
4 GREASE SEAL (2 per wheel)
4 ADAPTER, Caster Wheel (2 per wheel)
2 CAPSCREW, Hex Hd, 1/2-13 x 7-1/2
2 NUT, Hex, Nylon Lock, 1/2-13
2 WHEEL & TIRE ASSEMBLY, Rear, 23 x 9.5 x 12, Complete (Includes Ref 10 & 11)
2 TIRE, Rear, 23 x 9.5 x 12
2 WHEEL ASSEMBLY, Rear, for 23 x 9.5 x 12 Tires
10 WHEEL LUG, 1/2 x 1-5/8
45
