AND9902/D
AX5045 Programming
Manual
Ultra-Low Power Narrow-Band Sub GHz
(60−1050 MHz) RF Transceiver with
Integrated +23 dBm High Power Amplifier

OVERVIEW

AX5045 is a true single chip low-power CMOS
transceiver for narrow band applications. A fully integrated
VCO support most carrier frequencies from 60 MHz to
1050 MHz. The on-chip transceiver consists of a fully
integrated RF front-end with modulator, and demodulator.
Base band data processing is implemented in an advanced
and flexible communication controller that enables user
friendly communication via the SPI interface.
5
RX_P
LNA
6
RX_N
TX_P
3
PA
TX_N
4
VCHOKE
27
VDD_IO
1,23
Crystal
Oscillator
Divider
typ.
16 MHz
27
28
© Semiconductor Components Industries, LLC, 2019
March, 2021 − Rev. 1
AX5045
25
26
Mixer
IF Filter &
AGC PGAs
AGC
F
OUT
RF Frequency
F
XTAL
Generation
Subsystem
RF Output
60 MHz –
1.05 GHz
13
8
Figure 1. Functional Block Diagram of the AX5045
An on-chip low power oscillator as well as Wake-on-radio
enable very low power standby applications. Figure 1 shows
the block diagram of the AX5045.
Digital IF
De-
channel
ADC
modulator
filter
Modulator
Chip configuration
POR
References
Low Power
Oscillator
Wake on Radio
640 Hz/10kHz
Voltage
Regulator
7
23,1
23
1
www.onsemi.com
APPLICATION NOTE
12
11
Communication Controller &
Serial Interface
Registers
19 20 21
14 15 16 17
Publication Order Number:
SPI
AND9902/D
