EVBUM2511/D
)
EZAIRO
7150 SL Hybrid
Demonstrator Board
User's Manual
INTRODUCTION
Purpose
This document provides detailed information for the
configuration and use of the Ezairo 7150 SL hybrid
demonstrator board. The hybrid demonstrator board
consists of two printed circuit boards: a motherboard and
daughterboard that are designed to evaluate the performance
and capabilities of the Ezairo 7150 SL hybrid.
The Ezairo 7150 SL hybrid is a System-in-Package (SiP)
that includes the following:
ON Semiconductor Ezairo 7100 Digital Signal
Processor (DSP)
Nordic Semiconductor nRF51822 2.4 GHz Radio IC
ON Semiconductor 2 Mb EEPROM (EA2M) for
audiology
Conventions
The following conventions are used in this manual to
signify particular types of information:
Component and pin names, as well as file and path
names are in a monospace font
Variable path names (where you fill in suitable
information) and characters that you type are in a bold
monospace font
Default jumper configurations and items you see on the
screen are in a bold typeface.
Manual Organization
The Ezairo 7150 SL Hybrid Demonstrator Board User's
Guide contains the following chapters and appendices:
Introduction, describes the purpose and organization of
this manual, the intended audience, and provides a list
of recommended reading for more information.
Overview, provides an overview of the hybrid
demonstrator board for Ezairo 7150 SL.
Getting Started, explains how to use the hybrid
demonstrator board, and introduces the setup using the
Ezairo Sound Designer Software Application.
Hybrid Demonstrator Board, provides the details of the
hybrid demonstrator board. The chapter is divided into
the following topics:
The setup
© Semiconductor Components Industries, LLC, 2015
December, 2017 − Rev. 2
EVAL BOARD USER'S MANUAL
The design
Power supply
Digital input/output
2
I
C
CS44
Audio interfaces
Board configuration
Appendix A: Connectors, provides a complete list of the
connectors and jumpers on the hybrid demonstrator
board
Appendix B: Motherboard Schematics, contains the
motherboard schematics for the hybrid demonstrator
board
Appendix C: Daughterboard Schematics, contains the
daughterboard schematics for the hybrid demonstrator
board
Further Reading
For more information, refer to the following documents:
Promirat Serial Platform Quick Start Guide, available
at totalphase.com
Communication Accelerator Adaptor Manual, which is
installed with the Communication Accelerator Adaptor
(CAA) software
Ezairo 7150 SL Datasheet
EA2M Datasheet (available at www.onsemi.com)
Ezairo Sound Designer Software User Manual
1
www.onsemi.com
Publication Order Number:
EVBUM2511/D

Advertisement

loading
Need help?

Need help?

Do you have a question about the EZAIRO 7150 SL and is the answer not in the manual?

Questions and answers

Summary of Contents for ON Semiconductor EZAIRO 7150 SL

  • Page 1 Purpose This document provides detailed information for the EVAL BOARD USER’S MANUAL configuration and use of the Ezairo 7150 SL hybrid demonstrator board. The hybrid demonstrator board consists of two printed circuit boards: a motherboard and ♦ The design daughterboard that are designed to evaluate the performance ♦...
  • Page 2 The daughterboard was designed for • Access to all Ezairo 7150 SL digital input/output evaluating Ezairo 7150 SL as a smaller form factor, and it is signals via standard 0.1″ headers used for key measurements such as power consumption.
  • Page 3: Getting Started

    IC and the Ezairo 7100 on the board, you need some software development tools. Finally, if you would like to Powering the Ezairo 7150 SL Motherboard evaluate the volume control, this chapter describes 1. Connect the programmer to the header J2 on the connecting to the audio input/output.
  • Page 4 EVBUM2511/D Selecting the Power Supply To change the power supply for Ezairo 7150 SL, a different row of the header, PSU−SEL must be shorted. Table 1. EZAIRO 7150 SL MOTHERBOARD POWERING CONFIGURATION OPTIONS Pin Numbers Power Supply Additional Connections 1 and 2...
  • Page 5 Figure 1. Hybrid Demonstrator Board Setup Development Board Design The Ezairo 7150 SL hybrid is packaged in a 49-pin ball The following sections detail the various sub-circuits of grid array (BGA) package that is used on the hybrid the Ezairo 7150 SL hybrid demonstrator board;...
  • Page 6 EVBUM2511/D A block diagram showing all of the daughterboard circuit sections is shown in Figure 3. Figure 3. Daughterboard Circuit Location Block Diagram • The motherboard connects directly to the daughterboard ANT−2.4−CW−RAH−SMA−ND via a 36-pin header (X1). This is shown in Figure 4. from Linx Technologies For development purposes, we recommend using the following off-the-shelf SMA antenna:...
  • Page 7 EVBUM2511/D Here are the steps to setting up your product device for use times while using Sound Designer software, to get with the Ezairo Sound Designer software: immediate status information. NOTE: If you are programming the device with your own 6.
  • Page 8 Ezairo 7100 and nRF51822 inside the hybrid. The The headers VDDO2−SEL and VDDO3−SEL (refer to VDDO3 I/O voltage is used by Ezairo 7150 SL for its debug Table 4) configure the I/O voltages for each of these power port interface reset pin.
  • Page 9 The rest of the configurations depend on the power supply For electrical testing of Ezairo 7150 SL, we recommend input(s) that you choose. See Table 7. configuring the input ground to GNDA when the test equipment provides a single ended (unbalanced) output for www.onsemi.com...
  • Page 10 • Add a jumper to the PSU−SEL header to indicate the The VDDO3−SEL header can only be configured with powering method for Ezairo 7150 SL a jumper if the R3 and R7 resistors on the • Connect a jumper or ammeter to the VBAT−I header daughterboard are not populated •...
  • Page 11: Appendix A − Connectors

    VDDO2−SEL Ezairo 7150 SL VDDO2 voltage selection VDDO3−SEL Ezairo 7150 SL VDDO3 voltage selection VBAT−I Ezairo 7150 SL VBAT current header and power enable PSU−SEL Ezairo 7150 SL VBAT voltage selection MICGND Input ground connection to AGND or GNDMIC FILTEN0...
  • Page 12 Motherboard Connectors Table 12. MOTHERBOARD CONNECTOR DESCRIPTIONS Designator Description Reserved for ON Semiconductor internal use 6-pin DIN connector to any I C programmer, such as Promira, or HI−PRO, or other Ezairo 7100 development board Connector header for the daughterboard Table 13. DAUGHTERBOARD CONNECTOR DESCRIPTIONS...
  • Page 13: Appendix B − Motherboard Schematics

    EVBUM2511/D APPENDIX B − MOTHERBOARD SCHEMATICS Overview This appendix contains all schematics for the hybrid demonstrator board motherboard: • Daughterboard Connector • Communication Interfaces, Main PSU • Input/Output Connector Figure 5. Motherboard: Daughterboard Connector www.onsemi.com...
  • Page 14 EVBUM2511/D Figure 6. Motherboard: Communication Interfaces, Main PSU Figure 7. Motherboard: Input/Output Connectors www.onsemi.com...
  • Page 15: Appendix C − Daughterboard Schematic

    EVBUM2511/D APPENDIX C − DAUGHTERBOARD SCHEMATIC Overview This appendix contains the schematic for the hybrid demonstrator board single-ended antenna version of the daughterboard. Figure 8. Daughterboard: Ezairo 7150 SL, Motherboard Connector www.onsemi.com...
