- Page 1 GPS Vehicle tracker User manual S03C (Version V2.0) 1.Accessories Standard accessories: 1pc Charger 1pc USB cable 1pc Battery 5200mAh 1pc English Manual...
- Page 2 S03C Product Description GPS vehicle tracker Geo-fence Vibration alarm Voice monitoring With high intense magnet in its rear cover Low power alarm Battery with large capacity SOS emergency alarm Power-saving mode and avoid static drifting Specification GSM: MTK6223D GSM :850/ 900/ 1800/ 1900 MHz...
- Page 3 2.1 LED status (non-sleep mode) 2.1.1Red LED (Power/working status) LED Status Indication Flash quickly (interval 0.1S) Low battery Full charge/Working Flash slowly (interval 2s) normally Flash slowly (Flash 0.1s after Working normally every 2s) Bright Charging Dark Out of battery / Troubleshot 2.1.2 Blue LED（GPS signal status）...
- Page 4 (1) Power off the device, remove the battery and external power (2) Put the SIM card in the SIM card slot Note: 1. Please use a GSM SIM card 2. SIM card in the device should be enabled for GPRS 3.
- Page 5 (1) Below the front windshield with the device front up and make sure there are no sunshade mask and other anti-GPRS reception material on it (2) On the bottom of a car such as the side place below door. Do not put it too far inside, otherwise it can not receive GPS signal.
- Page 6 4.1.2 Server Parameter Setting SERVER,0,IP,Port,0# (With IP) SERVER,0,172.168.9.1,8800,0# 4.2 SOS Numbers Setting 4.2.1 Add SOS number by SMS SMS command: SOS,A,number 1,number 2,number 3,number 4#(A means add number) E.g. SOS,A,13510682360,13511685136,13612687248,13612683621# 4 SOS numbers can be set at one time. It will reply “OK” if succeeded. SOS,A,13527852360# means setting the first specific number SOS,A,,,13527852360,12510682360# means setting the third and fourth SOS number 4.2.2 Delete SOS numbers by SMS...
-
Page 7: Anti-Theft Alarm
4.3.1 Via Power ON/OFF button Short pressing Power button twice to activate defense status. The three LEDs will flash slowly one by one. After 3mins, the device will enter the defense status, and the LEDs will then flash quickly one by one. Short press Power button twice again to deactivate defense status 4.3.2 Via Calls Any SOS number calls the device and then ends up the call by the mobile side in 10s,... - Page 8 GPS location: “vibration ,Alarm: Date time：”12-10-31 20:08:18 http://maps.\google.com/maps?q=N22.577169,E113.916790.” LBS location: “vibration ,Alarm: Date time：12-10-31 20:08:18 http://maps.\google.com/maps?q=N22.577169,E113.916754.“ During vibration alarm time, if the device is located, but fail to connect to the platform, the device will send longitude and latitude information. E.g. “Vibration alarm: N23.111748, E114.409215, 11 While if the GPS is neither located nor connect to the platform, the device can not get the position information.
- Page 9 You can also set current location coordinates as the centre of the circular fence, “FENCE,ON,0,0,0,radius#” (This SMS command is only available when device get located) Go-in fence SMS: Any number can send the following message”FENCE,ON,0,latitude,longitude,radius,IN#” to turn on circular fence function e.g.
- Page 10 the longitude of upper left corner, the latitude of lower right corner, the longitude of lower right corner, IN#”. E.g. FENCE,ON,1,N22.541183,E113.916,N22.557743,E113.892334,IN# The terminal will reply “OK” if set successfully. Any time the terminal enters this rectangle fence, it will send alarm message to the preset SOS numbers. ...
- Page 11 4.6 Low battery alarm When battery is low, device will send low battery alarm SMS to SOS numbers Low battery alarm SMS: “Warning! Battery is low, please charge in time!” When battery is too low, it will send SMS: “Warning! Battery is too low, power off automatically.”...
- Page 12 building, it can not be located. Yet LBS can be located wherever there is GSM signal. 2. Only SOS numbers can query the position by SMS. 4.8.3 Position query via platform The device will send position information to the platform server timely. The user can check the position on the platform.
- Page 13 Send SMS command: mode,1# 4.11.2 Model2: Locating according to vibration mode (default) In this mode, the terminal will turn on GPS as default. If GPS locates, the terminal will send first GPS location to the platform. If GPS could not locate, it will upload LBS location. In this mode, if the terminal does not detect any vibration, GPS will be off.
- Page 14 table, or contact your service provider. Common Causes Solution problems Near the tall building or Change to a place Bad reception in the basement with good signal The terminal Change a new can not No battery power battery switch on Can not make No preset SOS numbers Set SOS numbers voice...
- Page 15 Other Setting command Command Format Example TIMER,LBS uploading time interval(min),GPS e.g.:TIMER,2,10# uploading time GPS/LBS LBS data uploading interval(second)# interval time interval:2 min; LBS uploading time setting GPS data uploading interval:1-60min; time interval:10 S; GPS uploading time interval:5-18000S; GMT,direction,serial,[15 ,30,45]# //direction,E or W, East Timezone or West// GMT,E,8#...
- Page 16 Software VERSION# version Parameters PARAM# GPRS GPRSSET# parameters Longitude WHERE# and latitude Check status STATUS# Location link URL# request Geo-fence SEEFENCE# check ERROR EXPLANATION ERROR 100 Command length is over the ruled length. Parameters of Command are over the ruled ERROR 101 length.
