Seeworld S708 User Manual

(gps+gsm+gprs vehicle tracker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GPS Vehicle Tracker
(GPS+GSM+GPRS)
SEEWORLD S708

User Manual

Please read the manual carefully before use the
GPS Tracker
so that you can install the device
correctly and activate it quickly on the internet. The
outlook and true color are subject to the actual product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S708 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seeworld S708

Summary of Contents for Seeworld S708

  • Page 1: User Manual

    GPS Vehicle Tracker (GPS+GSM+GPRS) SEEWORLD S708 User Manual Please read the manual carefully before use the GPS Tracker so that you can install the device correctly and activate it quickly on the internet. The outlook and true color are subject to the actual product.
  • Page 2 1.Technical parameter 1）.GSM：850/900/1800/1900MHz 2）.GPRS：Class12,TCP/IP 3）. Working Voltage：9-36V DC 4）. Working current：≈22mA (12vDC) 5）. Working current ：≈12mA (24vDC) 6）.GPS locating time ： Cold start ≈38s（Open sky） Warm start ≈32s Hot start ≈2s（Open sky） 7）.GPS Precision：10m（2D RM） 8）. Working temperature：-20℃～+70℃ 9）. Working humidity：20%～80%RH 10）.
  • Page 3 signal, the yellow-green LED flashes. 3.2 The blue LED in the front（GSM signal state） GSM signal is normal，blue LED light long bright。No GSM signal,the blue LED flashes。 GSM n o signal, flashes （ 0.2 sec/2 sec ） ， Signal normal long bright; All LEDS will turn off after 5 minutes.

  • Page 4: Text Command

    6.The Device Working 6.1 Power on: the device will be power on when connecting to the current. Then the green-yellow LED indicators will light continuously. (SIM work normal) The device will upload the location data to the online platform (the default interval of uploading data is 10seconds).

  • Page 5: Command Description

    1)Center number can control the oil and power and resume factory settings 2) Center number can receive the call and text of vibration alarm and over speeding alarm. 3) three number can be center number 4) add:sample1 add three number at the same Command time;sample2 add the first number ;sample3 add the Description...

  • Page 6: Text Command

    Parameter me, password] 2：APN,cmnet# differs according local telecom operators.Users have to comfirm the APN parameter Command For example：APN request password，please refer to Description Sample1，and Sample2 for no password. Command Successful Setting ： SET APN OK ！ Feedback 4)LANG Text Parameter Sample command 1：CHINESE...

  • Page 7: Command Description Command Feedback

    Description other information of the device Command Reply with current longitude and altitude, time,speed Feedback and IMEL. 7)URL Text Parameter Sample command WHERE URL# URL# Command Check the location link of Google map Description Command <Datetime:12-07-05 13:21:30> Feedback http://maps.google.com/maps?q=N22.540885,E113.95265 8)TIMER Text Parameter Sample...
  • Page 8 10)SPEEDING Text Parameter Sample command SPEEDING SPEEDING, speed 1)SPEEDING,120,3# Parameter [alarming way]# 2)SPEEDING,120# The speed scope is form 60-220, if the speed is not in this scope, the alarm is off. eg：SPEEDING,0# Command Alarming ways: 1, calling 2, texting, 3 calling and Description texting.

  • Page 9: Table Of Contents

    13)NUMBER Text command Text command Text command NUMBER NUMBER NUMBER Command Description Command Description Command Feedback Command Feedback 14)RESET Text command Parameter Sample RESET RESET# RESET# Command Description Reset the device Successful Setting ： RESET OK ！ Command Feedback 15)FEE command Parameter Sample...

  • Page 10: Special Announcement

    If not connected, suggesting that the Terminal is insufficient Or has been shut down If reminding the device SIM card is out of deposit, please make deposit by the telecom operator. ● If you can connect to the device when calling,and hear a beep. Du, du. noise the SIM card is installed correctly and has deposited and please check with your operator for GPRS function.
  • Page 11 4.Please properly keep this card and receipt in case of after-sales service 5.The following is for the warranty reference This form is the basic of the warranty certificate information, please fill out the form carefully Name Telephone Address Type IMEI Date Purchase name Agency address...
  • Page 12 The first time Maintenance Date company Fault statement Maintenance condition IMEI serviceman The second time Maintenanc Date company Fault statement Maintenanc e condition servicema IMEI Tenson Sales06@seeworld.hk...
