Summary of Contents for Seeworld S116
- Page 2 1． Accessories：...
- Page 3 2. Specification: 2.1.GSM frequency：850/900/1800/1900MHz 2.2. GPRS: Class12, UDP 2.3.Working Voltage：9-24V DC 2.4. Working Current：≈22mA (12vDC) 2.5. Working Current：≈12mA (24vDC) 2.6.GPS locating time：cold start≈38s（Open sky） Warm start≈32s Hot start≈2s（Open sky） 2.7.GPS precision：10m（2D RM） 2.8.Working temperature：-20℃～+70℃ 2.9.Working Humidity：20%～80%RH 2.10.Measurement：87（L）×43（W）×14（H）mm 3. Outlook...
- Page 4 4. Device status indicators 4.1 left red LED（power/ working condition） Connect DC 9-24V power supply and the red LED will light continuously. 4.2 Right green LED（GPS signal indicator） The LED glistens when getting the GPS signals normally. When the LED can not light or light continuously, the GPS can not get the signals. 4.3 Blue LED in the Middle（GSM signal indicator）...
- Page 5 5.1 Preparation for the installation 5.1.1 Product Check. Open the packing box and check the device‘s model and accessories. If the model is wrong or the accessories not complete, please contact the dealer. 5.1.2 Choose SIM card. Please insert a SIM card to the device. Please take dealer’s advice as reference.
- Page 6 without metal cover. Note：the metal cover will lessen the receiving of GPS signals.6. The device connecting requirements. 6.1 The device power supply is DC 9-24V. The red line is positive pole while the black line is negative pole. 6.2 The negative pole of power supply connects with ground or the metals.
- Page 7 8.1.3 Add or delete authorized number a d d a u t h o r i z e d n u m b e r ：text the command:#password#AUT1#mobile phone number# to the device’s SIM card number （ 1is authorized number 1， 2is authorized number 2） Succeeding reply：...
- Page 8 device’s SIM card number Succeeding reply：Reset the password ,OK! Failure reply：Format wrong! Note：Only admin can operate. 8.2 Obtain the longitude and latitude by mobile phone. Obtain the longitude and latitude by mobile phone：text the command:*password*LOCC# to the device’s SIM card number Succeeding reply：...
- Page 9 state ： text time interval when moving command:#password#MVUP#seconds# to the device’s SIM card number Succeeding reply： set movement upload time, OK! Failure reply： Format wrong! For example, if you want to set the time interval of moving state as 12 seconds，text the command：#8888#MVUP#12# Note：the default is 10 seconds.
- Page 10 Cancel the over speed alarm：text the command:#password#CLSA# to the device’s SIM card number Succeeding reply ： Close Speed Alarm, OK! Failure reply: Format wrong! Note：The default of this function is closed. Only admin and authorized number can operate. 8.7 Set and cancel the vibration alarm. ：...
- Page 11 Reply：web link, longitude and latitude, time, data, speed. 9.3 Chinese location check by texting 9.3.1 the command format：#password#ADRE#reply language# Reply: the current location 10. Trouble shooting 10.1 The device is not online or offline on the web platform. 10.1.1 First, please check the three LED working state. If possible, you can call the device’s number to check.
- Page 12 Warranty card of GPS Vehicle Tracker Special statement: 1.Technique of this product subject to change without further notice. 2.Any change about the appearance and color is subject to the real object. 3.Warranty card applies to the product with the IMEI number listed below.
- Page 13 Sales unit name Sales unit adress Sales unit Phone number 1.Main engine is guaranteed for one year for non-human damage Since the date of purchase. 2.The situations listed below are not in the scope of warranty, the users has to pay maintenance cost: (1) exxeed the warranty period;...
- Page 14 Maintenance status IMEI number Serviceman Record two Maintenance Date unit Fault description Maintenance status IMEI number Serviceman...
