Brocade Communications Systems 6520 Reference Manual

Brocade Communications Systems 6520 Reference Manual

96-port auto-sensing 2, 4, 8, or 16 gbps as well as 10 gbps fibre channel (fc) switch
Hide thumbs Also See for 6520:
Table of Contents

Advertisement

Quick Links

See also: Administrator's Manual
DRAFT: BROCADE CONFIDENTIAL
53-1002705-01
®
15 December 2012
Brocade 6520
Hardware Reference Manual
