Menus
Setup is accomplished using menus and setup screens accessed by holding
the UP and DOWN arrow buttons at turn on, and by pressing the AUDIO and
FREQ buttons when the unit is turned on.

Hold UP arrow at turn on.

Hold the UP arrow button in while pressing both AUDIO and FREQ buttons to
access the setup screens below. It's easier if you lay the unit on a flat surface
and use two hands to press all three buttons at the same time. After the first
screen loads, press the AUDIO button repeatedly to switch between the set-
tings. Press the UP and DOWN arrow buttons for the desired selection.
After the settings are made, press both AUDIO and FREQ buttons together to
exit and turn the power off.
CP (compatibility modes)
Allows the transmitter to be used with 941 Series receivers or IFB systems in
the 941 MHz band.
nHb
new hybrid mode (ETSI compliant)
IFb
Lectrosonics IFB systems
NOTE: The nHb compatibility mode is the same as the NU HYBR
mode in the SRc-941 receiver.
Pr (power output)
Can be set at 100 for slightly increased range or at 50 for longer battery life.
50
50 mW output and longer battery life when
maximum range is not necessary
100 100 mW for slightly increased range
NOTE: See battery life table in the specifications
bL (backlight settings)
Adjusts how long the LCD stays lit after pressing buttons.
5
30
on
StP (Frequency step size)
Sets the increments of frequency adjustment.
100
25
www.lectrosonics.com
5 minutes
30 seconds
Stays on
100 kHz steps
25 kHz steps
