2.5.4

Personal safety equipment

Symbol Meaning
Wear body protection
Wear ear protectors
2.5.5

Recycling

Symbol Meaning
Recycling, to avoid waste, collect all
materials for reuse
2.5.6

Grounding symbol

Symbol Meaning
Ground connection
2.5.7

ESD symbol

Symbol Meaning
ESD: Electrostatic Sensitive Devices,
i.e. components and assemblies sensi-
tive to electrostatic energy
2.5.8

Information signs

Symbol Meaning
Tips and information making using the
frequency inverter easier.
2.5.9

Font style in documentation

Example Font style
1234 bold
inclined,
Parameter
font: Times New Ro-
man
P.1234 bold
Q.1234 bold
2.6

Directives and guidelines to be adhered to by the operator

The operator must follow the following directives and regulations:
 Ensure that the applicable workplace-related accident prevention regulations as well as other ap-
plicable national regulation are accessible to the staff.
 An authorized person must ensure, before using the frequency inverter, that the device is used in
compliance with its designated use and that all safety requirements are met.
 Additionally, comply with the applicable laws, regulations and directives of the country in which
the frequency inverter is used.
 For liquid cooled frequency inverters, comply with the cooling water guideline VGB-R 455 P.
 Any additional guidelines and directives that may be required additionally shall be defined by the
operator of the machine/plant considering the operating environment.
11/17
Use
Representation of parameter numbers
Representation of parameter names
Representation of parameter numbers without name, e.g. in formulas
Representation of source numbers
Liquid Cooling ACU/ANG/AEC 9
