Size 5 (Liquid-Cooled) - BONFIGLIOLI Active Cube Series Complement To Operating Instructions

5.1

Size 5 (liquid-cooled)

The frequency inverter is mounted in a vertical position on the assembly panel. The following illustration
shows the standard fitting.
b1
a1
Dimensions [mm]
a b
400 300
Assembly is done by screwing the two fixing brackets to the heat sink of the frequency inverter and the
assembly panel.
The frequency inverters are provided with fixing brackets, which are fitted using four thread-cutting
screws. The dimensions of the device and the installation dimensions are those of the standard device
without optional components and are given in millimeters.
20
Standard installation
b
b2
b2
c a1
220 450 ... 464
Liquid Cooling ACU / ANG /AEC
a a2
Assembly dimensions [mm]
a2 b1
480 28
c
c1
ACU210Size5-TZ-LiquidCooling_01-V00
b2 c1
244 97
11/17
