vita SMART.FIRE Operating Manual

Hide thumbs Also See for VITA SMART.FIRE:
Table of Contents

Advertisement

Quick Links

VITA SMART.FIRE
Operating manual
VITA shade determination
®
VITA Farbkommunikation
VITA Farbkommunikation
VITA shade communication
VITABLOCS
VITABLOCS
CELTRA DUO
Stains fixation firing
GLAZE LT SPRAY
Stains fixation firing
IPS Empress CAD
IPS Empress CAD
IPS e.max CAD
Stains fixation firing
GLAZE LT SPRAY
crystallization
IPS e.max CAD
SUPRINITY PC
SUPRINITY PC
GLAZE LT SPRAY
crystallization
Stains fixation firing
VITA shade reproduction
VITA – perfect match.
CELTRA DUO
GLAZE LT SPRAY
IPS e.max CAD
Stains fixation firing
STANDARD
SUPRINITY PC
GLAZE LT SPRAY
VITA shade control
Date of issue: 05.18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VITA SMART.FIRE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for vita VITA SMART.FIRE

Summary of Contents for vita VITA SMART.FIRE

  • Page 1 SUPRINITY PC SUPRINITY PC SUPRINITY PC GLAZE LT SPRAY crystallization Stains fixation firing GLAZE LT SPRAY VITA Farbkommunikation VITA Farbkommunikation VITA shade determination VITA shade communication VITA shade reproduction VITA shade control Date of issue: 05.18 VITA – perfect match.
  • Page 2 The efficient firing unit for chairside restorations Dear customer, Congratulations and thank you for choosing the VITA SMART.FIRE firing system. The VITA SMART.FIRE firing system is manufactured using the highest quality standards, and is equipped with modern hardware and software for easy and intuitive control and operation.

  • Page 3: Table Of Contents

    7.1 VITA SMART.FIRE scope of supply ..... . . 37 7.2 VITA system solutions....... . . 38 8.
  • Page 4 VITABLOCS VITABLOCS CELTRA DUO CELTRA DUO Stains fixation firing GLAZE LT SPRAY Stains fixation firing GLAZE LT SPRAY IPS Empress CAD IPS Empress CAD IPS e.max CAD IPS e.max CAD Stains fixation firing GLAZE LT SPRAY crystallization Stains fixation firing STANDARD IPS e.max CAD SUPRINITY PC...

  • Page 5: The System

    1. The system 2. First use 1. The system VITA SMART.FIRE System VITA SMART.FIRE VITA SMART.FIRE VITA SMART.FIRE Chairside firing unit Control unit Accessories 1.1 The firing unit Main switch Mains power Power connection supply connection for vacuum pump Furnace head...

  • Page 6: The Control Unit

    1. The system 2. First use 1.2 The control unit USB ports(1 + 2) Firing unit port SD card slot Note: • What? Control unit with preinstalled programs for all common chairside materials. • What for? For intuitively easy firing. 1.3 Accessories Platinum pins = 2 pieces (molar, anterior tooth) Firing tray Ø...

  • Page 7: Starting Firing In 6 Steps

    1. The system 2. First use 3. Operation 2. First use 2.1 Starting firing in 6 steps Connect the firing unit and the control Connect the firing unit to the power Turn on the main switch. unit to the connecting cable. supply.

  • Page 8: Switching Off The Firing Unit And Control Unit

    • Screen cleaners are especially good since they do not cause any scratches, have an antistatic effect and prevent further dirt accumulation. Please note: • Damage to the display resulting from improper use during operation or cleaning is excluded from the VITA warranty.

  • Page 9: Gesture Controls Of The Control Unit

    2. First use 3. Operation 4. Desktop management 3. Operation 3.1 Gesture controls of the control unit Swiping To go to the next desktop, swipe right or left on the desktop. Zooming You can zoom in and out of photos or PDFs by using two fingers to maximize or minimize the image.

  • Page 10: Starting Firing And Basic Firing Window

    2. First use 3. Operation 4. Desktop management 3.2 Starting firing and basic firing window Status display Back button Start and stop firing Assistance Detailed firing window function Note: • Select the firing program and go to the basic firing window by briefly tapping the program button. 3.3 Firing status indicators in the basic firing window 3rd phase: The icon lights up blue.

  • Page 11: Assistance Function

    2. First use 3. Operation 4. Desktop management 3.4 Assistance function Tap the assistance function. Select item 1, "Prepare restoration." Tap on a word highlighted in blue to open an image or tutorial video. Example image for using Choose this option to open This takes you to the video tutorial occlusion paper the material overview for the...

  • Page 12: System Functions

    3. Operation 2. First use 4. Desktop management 3.5 System functions Displayed function area Desktop area Hidden function area Note: • You can display function areas by tapping the top and the side areas of the screen. You can hide the two function areas by tapping the arrows on the edge of the screen. Return to home desktop File manager...

  • Page 13: Sleep Mode

    • What for? Prevents loss of time by automatically preheating the firing unit so that firing can begin quickly. VITA AntiCon. If the firing unit is switched off for an extended period of time, the firing chamber is heated for 5 minutes while slightly open the next time the firing unit is switched on and the standby temperature is activated.

  • Page 14: File Manager

    • File manager for creating a custom desktop and for flexible file management • It allows you to copy and delete firing programs, PDF documents and images. • The "VITA" folder contains all preinstalled programs for VITA materials. You can transfer these programs to the desired desktop.

  • Page 15: Settings

    2. First use 3. Operation 4. Desktop management Example: transferring a program in the file manager Tap the file manager. Select the "VITA" folder. Select the folder, for example "VITABLOCS." Select the firing, for example Select the target desktop as default, "Standard"...

  • Page 16: General Help

    3.10 General help Note: • What? The "General Help" function button takes you to processing and operating instructions for VITA CAD / CAM materials, VITA veneering materials and VITA devices. The help function consists of two pages. • What for? Quick assistance, thanks to preinstalled processing instructions and operating manuals.

  • Page 17: Desktop Editing Menu

    3. Operation 4. Desktop management 5. Button management 4. Desktop management Desktop Note: • The area inside the dotted magenta outline is the desktop. This is the workspace where firing programs, images and PDFs can be stored. 4.1 Desktop editing menu Desktop editing menu Note: •...

  • Page 18: Naming The Desktop

    3. Operation 4. Desktop management 5. Button management 4.2. Naming a desktop Screen Press on the desktop and hold until Choose "Name desktop." Enter the desktop name. the desktop editing menu appears. Tap the desktop to close the editing Renamed desktop. menu.

  • Page 19: Desktop Information

    3. Operation 4. Desktop management 5. Button management 4.4 Desktop information Press on the desktop and hold until the Choose "Desktop info." Tap the input field. desktop editing menu appears. Now you can add information about the desktop. Note • What? You can store information about the desktop here. •...

  • Page 20: Copying A Desktop

    3. Operation 4. Desktop management 5. Button management 4.6 Copying desktop Press on the desktop and hold until the Select "Copy desktop." Desktop editing menu desktop editing menu appears. is automatically hidden. Select the desktop and activate the Select "Paste desktop." Copy of the desktop.

  • Page 21: Pasting A Desktop

    3. Operation 4. Desktop management 5. Button management 4.8 Pasting a desktop Please note: • This function is only active in combination with the desktop copy function and the desktop paste function. 4.9 Deleting a desktop Press on the desktop and hold until the Select "Delete desktop"...
  • Page 22 VITABLOCS VITABLOCS VITABLOCS SUPRINITY PC Stains fixation firing GLAZE LT POWDER Corrective firing crystallization PRINITY PC SUPRINITY PC SUPRINITY PC Dentine firing Stains fixation firing GLAZE LT Powder STANDARD 22 22...

  • Page 23: Button Editing Menu

    4. Desktop management 5. Button management 6. Detailed firing window 5. Button management 5.1 Button editing menu Hold down the button until the button Tap the desktop to close the editing editing menu is activated. menu. Naming button Configure button Store information button Create new firing program Copy button...

  • Page 24: Moving A Button

    5. Button management 4. Desktop management 6. Detailed firing window 5.3 Moving a button Hold down the button and move it to the Repositioned button. desired position. Note: • What? This function allows you to reposition the button on the desktop. •...

  • Page 25: Configuring A Button

    4. Desktop management 5. Button management 6. Detailed firing window 5.5 Configuring a button Hold down the button until the button Select "Configure button." Select the icon and background color. editing menu is activated. Configured button. Tap the desktop to close the editing menu.

  • Page 26: Creating A New Firing Program

    Firing curve types Predrying curve = e.g. drying stained zirconium restorations Single-stage curve = standard firing curve, for most firing programs on the market, e.g. VITA SUPRINITY PC Two-stage curve = special programs, e.g. IPS e.max CAD crystallization 26 26...

  • Page 27: Copying A Button

    4. Desktop management 5. Button management 6. Detailed firing window 5.8 Copying a button Hold down the button until the button Select "Copy button." Select the desktop and activate the editing menu is activated. button editing menu. Select "Paste button." Copied button.

  • Page 28: Pasting A Button

    4. Desktop management 5. Button management 6. Detailed firing window 5.10 Pasting a button Note: • This function is only active in combination with the cut function and the paste function. 5.11 Deleting a button Hold down the button until the button Select "Delete button."...

  • Page 29: Detailed Firing Window For Firing Process

    5. Button management 6. Detailed firing window 7. Scope of supply / system solutions 6. Detailed firing window 6.1 Detailed firing window for firing process Firing temperature and holding time Rise time/temperature Cooling temperature Predrying tempera- ture / predrying time Cooling lift position Predrying lift position Process data...

  • Page 30: Predrying Temperature / Predrying Time

    5. Button management 6. Detailed firing window 7. Scope of supply / system solutions 6.2 Predrying temperature / predrying time Values are saved Old values are retained and the system returns to the firing curve Modifiable parameters • Predrying temperature: 60°C –600°C •...

  • Page 31: Prevacuum

    5. Button management 6. Detailed firing window 7. Scope of supply / system solutions 6.4 Prevacuum Values are saved Old values are retained and the system returns to the firing curve Modifiable parameters: • Pre-vacuum time: 00:00 min - 10:00 min Note: •...

  • Page 32: Main Vacuum

    5. Button management 6. Detailed firing window 7. Scope of supply / system solutions 6.6 Main vacuum Values are saved Old values are retained and the system returns to the firing curve Modifiable parameters: • Main vacuum time: 00:00 min - 90:00 min •...

  • Page 33: Cooling Temperature

    5. Button management 6. Detailed firing window 7. Scope of supply / system solutions 6.8 Cooling temperature Values are saved Old values are retained and the system returns to the firing curve Modifiable parameters: • Cooling temperature: 60°C – 600°C Note: •...

  • Page 34: Changes After Program Start

    5. Button management 6. Detailed firing window 7. Scope of supply / system solutions 6.10 Changes after program start Note: • Changes of program values are possible after starting a firing program. To avoid misfires, changes which automatically impact other program areas are not allowed, such as changes in the rise time, which causes an automatic adjustment of the vacuum time.
  • Page 35 5. Button management 6. Detailed firing window 7. Scope of supply / system solutions...
  • Page 36 6. Detailed firing window 7. Scope of supply / system solutions 8. Technical data / information VITABLOCS VITABLOCS CELTRA DUO CELTRA DUO Stains fixing firing GLAZE LT SPRAY Stains fixing firing GLAZE LT SPRAY IPS Empress CAD IPS Empress CAD IPS e.max CAD IPS e.max CAD Stains fixing firing...

  • Page 37: Vita Smart.fire Scope Of Supply

    6) 220 V – 230 V ZA 7) 220 V – 230 V AU 8) 220 V – 230 V IL DARD Operating manual for the VITA SMART.FIRE firing system Note: • All VITA SMART.FIRE components can be individually reordered.

  • Page 38: Vita System Solutions

    • Use VITA AKZENT Plus masking and glazing stains for feldspar and glass ceramics. Shade modification* • Use VITA platinum pins and VITA Firing Paste to ensure that the restoration is securely placed on the firing tray. Firing preparation • Use the VITA SMART.FIRE firing unit for crystallization, glaze, stain and corrective firing of all common chairside materials.

  • Page 39: Technical Data For Firing Unit

    European Union (EU). Old units can be returned to VITA Zahnfabrik. CE marking VITA SMART.FIRE complies with the applicable regulations of the European Union (EU). The declaration of conformity can be requested from VITA (Regulatory Affairs Department) at: www.vita-zahnfabrik.com...

  • Page 40: Information

    8. Technical data / information 7. Scope of supply / system solutions 9. Additional information 8.4 Information Basic information on the instrument design • The instrument is designed according to state-of-the-art technology and recognized safety standards. • However, if it is used inappropriately, hazards for the health and safety of the operating personnel or third parties, as well as the risk of damaging the instrument and other material property, may arise.

  • Page 41: Safety Functions

    7. Scope of supply / system solutions 8. Technical data / information 9. Additional information 8.5 Safety functions The firing unit has the following safety and monitoring features: 1. Temperature sensor monitoring 2. Power supply failure protection 3. Obstruction sensor 4.

  • Page 42: Competitor Material In The Vita Smart.fire

    The VITA SMART.FIRE contains firing programs for Celtra Duo, IPS e.max CAD, and IPS Empress CAD. However, it should be noted that the firings for IPS e.max CAD in VITA SMART.FIRE must be carried out on an Ivoclar Vivadent firing tray. The firings for IPS Empress CAD and Celtra Duo can be carried out on the VITA SMART.FIRE round firing tray with VITA platinum pins.

  • Page 43: Hotline And Support

    Mr. Udo Wolfner and his team (Internal If you have technical questions Sales Department) will be glad to assist you concerning VITA product solutions, with orders or questions about delivery, you can contact our technical specialists, product data and marketing materials.
  • Page 44 Claims for damages based on fault liability (culpa in con- trahendo, breach of contract, unlawful acts, etc.) can only be made in the case of intent or gross negligence. The VITA Modulbox is not necessarily a component of the product. Date of issue of this product information: 05.18 After the publication of this information for use any previous versions become obsolete.
