VITA FDS – Firing Data System
Operating manual
VITA shade taking
VITA shade communication
VITA shade reproduction
VITA shade control
Date of issue: 04.11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VITA FDS and is the answer not in the manual?

Questions and answers

Summary of Contents for vita VITA FDS

  • Page 1 VITA FDS – Firing Data System Operating manual VITA shade taking VITA shade communication VITA shade reproduction VITA shade control Date of issue: 04.11...
  • Page 2: Table Of Contents

    Graphic display Zoom in / zoom out 5.2 Move section 5.3 Firing curve view and evaluation of paramaters Edit Search data record Delete record Settings Language Options Information Help 8.2 About VITA FDS 8.3 Licence Infomration (EULA) Warranty and liability Service...
  • Page 3: Preface

    This publication is protected by copyright. Any use beyond the limitations of the copyright law without the approval of VITA Zahnfabrik H. Rauter GmbH & Co. KG shall be forbidden and punishable by law. This applies in particular to reproductions, translations, archiving on microfilm...
  • Page 4: Scope Of Delivery

    English version of Windows XP <program files> stands for C:\program files. • Installation directory of the data: By default FDS searches for data in the directory C:\VITA\VITA-FDS. The individual databases are saved in this directory.
  • Page 5: Databases

    4.1 Create new database File > Create new database This menu option creates a new database in C:\VITA\VITA-FDS. The name of the database can be chosen freely according to the rules for Windows file names, i.e. only letters and numbers may be used.
  • Page 6: Open Database

    4.2 Open database File > Open database The menu option Open database opens a range of databases in the directory C:\VITA\VITA-FDS\. After the appropriate database is selected it will be opened for editing by pressing the Open button. 4.3 Close database File >...
  • Page 7: Import Process Data

    VITA Firing Data System 4.4 Import process data File > Import process data This menu item imports a process data file from a volume (e.g. USB stick) into an open database. Select the desired process data file and click the Open button.
  • Page 8: Print

    VITA Firing Data System 4.6 Print File > Print Here the number of copies and the printer can be selected. The current process data record is printed by pressing the OK button. 4.7 Exit program File > Exit program The FDS program is closed by selecting the menu item Exit program.
  • Page 9: Graphic Display

    VITA Firing Data System 5 Graphic display The graphic display shows the chronological sequence (in min) of the firing curve. Figure 1 shows a 1-step firing program On the left side the following parameters are displayed: Operator Material Program Storage date...
  • Page 10: Zoom In / Zoom Out

    VITA Firing Data System The following parameters are displayed for process data of pressing programs: Figure 3 shows a pressing program On the left side the following parameters are displayed: Start temperature Press temperature Forming pressure (1) Forming time (1)
  • Page 11: Move Section

    VITA Firing Data System 5.2 Move section Move the scroll bar in the desired direction to move the firing curve sections up or down. Move the scroll bar below in the desired direction to move the firing curve sections to the right or to the left. (see page 9, figure 1) 5.3 Firing curve view and evaluation of parameters...
  • Page 12: Edit

    VITA Firing Data System 6 Edit 6.1 Search data record The following criteria can be used to search for process data sets: Operator Material Program Date (from) Date (until) Device type Device number Order number Name Notice Remarks If the search should be case-sensitive, the corresponding option must be selected by clicking it.
  • Page 13: Delete Record

    VITA Firing Data System 6.2 Delete record After selecting the menu item Delete record you are prompted to confirm the deletion of the record displayed. The current record will be permanently deleted by pressing the OK button. 7 Settings 7.1 Language Here one of the following languages can be selected: German, English, and French.
  • Page 14: Information

    The 'Acrobat Reader' software by Adobe is required to view and print the PDF document. A free download of the software is available at http://get.adobe. com/de/reader/. 8.2 About VITA FDS Here you find general information on the software. 8.3 License information (EULA) Here you find the software license agreement.
  • Page 15: Service

    Further information about the device is available on the homepage: www.vita-zahnfabrik.com/update-messenger/en Software updates can be downloaded under Services / Equipment Servicing. Moreover there is also a registration possibility for the VITA Update Messenger to be automatically informed by email about new information on the device and software.
  • Page 16 With the unique VITA SYSTEM 3D-MASTER all natural tooth shades are systematically determined and completely repro- duced. Please note: Our products should be used according to the working instructions. We cannot be held liable for damages resulting from incorrect handling or usage.
