- Page 1 Instructions for use VITA SMART.FIRE® ADVANCED The compact and modern furnace for dental practices and laboratories with space for bridges with up to 14 units.
-
Page 2: The Furnace
We are pleased that you have chosen the VITA SMART.FIRE ADVANCED furnace. The VITA SMART.FIRE ADVANCED combines ultra-modern design with impressive firing quality. Thanks to its compact design, it even offers ample space for 14-unit bridges – making it ideal not only for your practice, but also for all laboratories. -
Page 3: Table Of Contents
5.1 Competitor material in the VITA SMART.FIRE ADVANCED ..14 5.2 VITA warranty and consumer protection ..... . 14 5.3 Update messenger . - Page 4 1. The system VITA SMART.FIRE ADVANCED System VITA SMART.FIRE ADVANCED VITA vPad excellence VITA SMART.FIRE ADVANCED Furnace Control unit Accessories 1.1 The firing unit The compact firing unit in practices and laboratories for veneering, crystallization, glaze, stains and corrective firings.
-
Page 5: The Control Unit
1.2 The control unit The VITA vPad excellence for easy firing using pre-installed programs for all common chairside materials (not included in the scope of delivery). USB ports (1 + 2) Firing unit port SD card slot 1.3 Accessories The integrated accessories drawer ensures that everything you need is always at hand. -
Page 6: First Use
2. First use 2.1 Starting firing in six steps Connect the firing unit and control unit Connect the firing unit to the power Press the main switch. using the connection cable. supply. Hang up the two storage trays. Select the firing program. Start the firing process. -
Page 7: Setting Up The Firing Unit
• Screen cleaners are especially good since they do not cause any scratches, have an antistatic effect and prevent further dirt accumulation. Please note Damage to the display resulting from improper use during operation or cleaning is excluded from the VITA warranty. -
Page 8: Scope Of Supply / System Solutions
6) 220 V – 230 V ZA 7) 220 V – 230 V AU 8) 220 V – 230 V IL Instructions for use for the VITA SMART.FIRE ADVANCED firing system Note All VITA SMART.FIRE ADVANCED components can be individually reordered. -
Page 11: Technical Data / Information
Old units can be returned to VITA Zahnfabrik. VITA SMART.FIRE ADVANCED complies with the applicable regulations CE marking of the European Union (EU). The declaration of conformity can be accessed on the homepage under MyVITA or requested directly from VITA Zahnfabrik. -
Page 12: Information
4. Technical data / information 4.3 Information Basic information on the device design • The instrument is designed according to state-of-the-art • However, if it is used inappropriately, hazards for the health technology and recognized safety standards. and safety of the operating personnel or third parties, as well as the risk of damaging the instrument and other material property, may arise. -
Page 13: Safety Functions
4.4 Safety functions The firing unit is equipped with the following safety and monitoring features: 1. Temperature sensor monitoring 2. Power supply failure protection 3. Obstruction sensor 4. Temperature protection switch 5. Automatic temperature cold spot compensation Temperature sensor monitoring The temperature sensor monitoring feature detects a failure of temperature sensor has been detected, the firing chamber is the temperature sensor in the firing chamber. -
Page 14: Additional Information
Celtra Duo, IPS e.max CAD and IPS Empress CAD. However, it VITA SMART.FIRE ADVANCED for Celtra Duo, IPS e.max CAD, should be noted that the firings for IPS e.max CAD in VITA SMART. and IPS Empress CAD are to be used as guide values. Users must... -
Page 15: Hotline And Support
The products/systems of other manufacturers mentioned in The VITA Modulbox is not a necessary part of the product. this document are registered trademarks of the respective Publication of this product brochure: 2024-08 manufacturers. More information on VITA SMART.FIRE ADVANCED:... - Page 16 VITA SMART.FIRE® ADVANCED VITA Zahnfabrik H. Rauter GmbH & Co. KG Spitalgasse 3 79713 Bad Säckingen Phone: +49 7761 562-0 info@vita-zahnfabrik.com Follow us on Germany Hotline: +49 7761 562-222 www.vita-zahnfabrik.com social media!
