Epcom EPIG5K User Manual page 8

DC switch
Figure 3 External Appearance of
Information
Installation method as shown in the 5.5.1 of "Ⅰ".
DC switch
Figure 4 External Appearance of the special
Information
Installation method as shown in the 5.5.1 of "Ⅱ".
Information
The PV input has one channel of MPPT which consists of three pairs of
terminals, so there can be max three PV strings connecting to the channel.
PV Input
PV Input
- 6 -
RS485
Communication
Terminal
AC Output
RS485
Communication
Terminal
AC Output
