Product Description - Epcom EPIG5K User Manual

WARNING!
Do not change the internal components of the inverter without permission.
WARNING!
If the equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
3

Product Description

3.1 Photovoltaic/PV grid-connected system
PV grid-connected system consists of PV modules, grid-connected inverters,
metering device and power distribution system (Figure 1).
The solar energy is converted into DC current by PV modules and then feeding into
the local power grid network by the grid-connected inverter which synchronizing the
frequency, phase and pure sine waveform with the power network.
PV modules
Combiner box
Figure 1 PV grid-connected system
Metering
Inverter
- 4 -
Power grid
