Epcom EPIG5K User Manual page 11

Grid lower
/over-frequency
protection points
Residual current monitoring
Fault current monitoring
Anti-islanding protection
Standard
Safety
certification
EMC
EMI
Functional safety and anti-islanding
Remark: Europe efficiency calculate :
η
=
Euro
Others
Items
Radiation noise
Conducted noise
AC short circuit protection
Lightning resistant
ESD Protection
Noise
Vibration resistance
Durable years
Environmental conditions
Items
Operating temperature
Altitude
Relative humidity
Noise level
Cooling Method
* Above data just for reference. If there is a change, please refer to the machine.
TUV: DIN VDE
0126-1-1
G59/2
G83-1
AS4777
η η
+ +
. 0 03 . 0 06
5 % 10 %
Specification
CISPR22 Class A
CISPR22 Class A
Yes（current limited）
1.2uS X 50uS 5kV
Case to operational part 15kV
<50dB 1m
JEC-5917
20 years
Comply with DIN VDE 0126-1-1
Comply with DIN VDE 0126-1-1
Comply with DIN VDE 0126-1-1
IEC 62109-1，IEC 62109-2
VDE/TUV/CE
EN61000-6-1,EN61000-1-2;Class B
EN61000-6-3,EN61000-1-4
DIN VDE0126-1-1/AS4777/G83-1/G59-2
η η
+
. 0 13 . 0 10
20 % 30 %
5Hz 1G 30times at X・Y direction
10Hz 1G 30times at X・Y direction
5Hz 0.5G 30times at Z direction
10Hz 0.5G 30times at Z direction
Specification
-20℃~ +50℃
2000 m
4% ~ 100 %
＜50dB 1m
Natural cooling
- 9 -
50.2Hz/47.5Hz
η η
+ +
. 0 48 . 0 20
50 % 100
Remarks
DC/AC to ground
System can work normally
Average temperature 25℃ 12H/day
X
%
Remarks
