Step 1: Put the wires through Screw Cap, Adapter Body of the AC female connector.
Keep the wire L, N, PE corresponding to 1、 3、
inverter correctly.
Step 2: Screw these components tightly after connecting the wires.
Step 3: Finally, connect AC female terminal to AC male terminal on inverter ,tighten
the cable and then screw them tightly together.
1 L
Wire red
3 N
Wire black
Wire yellow&green
PE
Attention！
Please ensure the corresponding relationship between polarity
the core cable and the holes of the terminal is the correct
of the AC male connector on the
