Valcom VIP-130AL Manual page 5

SIDE
SIDE
RJ45 NETWORK
CONNECTION
STANDARD
RJ45 PATCH CABLE
(T568B)
RJ45 NETWORK
CONNECTION
HORN SIGNAL CONNECTION
RJ-45
Typical 568B
RJ-45 Jack
CAT 3/5/6
*The Maximum Recommended Distance
From the IP Link to the Horn is 350'.
Figure 4. Audio Connections
5
HORN
RJ45
BROWN
BROWN
BROWN
WHITE/BROWN
WHITE/BROWN
GREEN
GREEN
WHITE/GREEN
WHITE/GREEN
ORANGE
ORANGE
WHITE/ORANGE
WHITE/ORANGE
BLUE BLUE
WHITE/BLUE
WHITE/BLUE
BLUE
VM-186
HORN
947812
