HP-4 Recessed / Regressed
Mounting and Feed Guide
Conduit Plate - Front (Standard)
43704
Recessed T-Bar Luminaire Lengths (C1, C2, C3, C3F, C1T, C2T, TZ6)
46-7/8"
4'
94-7/8"
8'
142-7/8"
12'
94-7/8"
16'
142-7/8"
20'
142-7/8"
24'
All starter/independent luminaires are 1-1/8" shorter than nominal. All joiner/ender luminaires are normal length.
Recessed Non-T-Bar Support Locations (VF, SF)
36"
48"
84"
96"
132"
144"
84"
96"
Starter
132"
144"
Starter
132"
144"
Starter

FEED OPTIONS

Conduit Plate - Top
45086
96"
96"
96"
96"
96"
96"
144"
144"
Finelite, Inc. • 30500 Whipple Road • Union City, CA 94587-1530 • 510 / 441-1100 • FAX: 510 / 441-1510 • www.finelite.com
Recessed Regressed
144"
#8 Joiner Plate
Screw Hole
1-1/2"
6"
Nominal Length
Note: Dimensions do not include endcaps.
Splice Box
89069
1/4"-20 Threaded Rod
Mounting Hole
1/4"-20 Threaded Rod
1-1/2"
Mounting Hole
6"
12' MAXIMUM SECTION LENGTH.
#8 Joiner Plate
Screw Hole
