Finelite HP-2 Installation Instructions

HP-2 Direct Starter/Independent Installation Instructions
Scan QR code for
Ceiling
helpful video(s)
Cable Bushing
0 - 10V
Dimming
Aircraft Cable
Luminaire
Locate aircraft cables.
Step 3
GridBox™
Threaded
Canopy
Coupler
Power Feed
Aircraft
Cable
Install power cable through canopy and into GridBox™. Make electrical connections in GridBox.
Note: All power connections to be installed to
local/national codes by a Certified Electrician.
Step 1
Gripper
Power Cord
Threaded
Stud
Install grippers onto threaded studs on both ends Install GridBox™ and caddy clip onto ceiling grid, then canopies and aircraft cable assemblies. A. Align aircraft cables to grippers and insert on
of the luminaire. both ends of the luminaire. Adjust pendant to proper height and level. Press down on top of gripper to release locking mechanism if needed.
Secure luminaire to structure using tie-wire (by others) according to code. B. End plates are adjustable for custom mounting locations.
Remove #8-18 x 1/4" screw (provided) from end plate, then slide end plate to desired location and reinstall #8-18 x 1/4" screw.
GridBox™
Secure to Structure
(by others)
Caddy Clip
Finelite, Inc. • 30500 Whipple Road • Union City, CA 94587-1530 • (510) 441-1100 • Fax: (510) 441-1510 • www.finelite.com
Step 2
Aircraft
Cable
A
Aircraft
Power
Cable
Cord
Press Down
Here to Release
Locking
Mechanism
Gripper
Step 4
Slide safety stop and safety crimp up to the aircraft cable within 9" of cable gripper. Trim excess cable and insert safety bar
assembly through feed hole. Turn power on to luminaire.
GridBox™
Canopy
Secure to Structure
#8-18 x 1/4" Screw
(by others)
Power
(provided)
Cable
Caddy Clip
Power Cord
Gripper
Feed Hole
Safety Stop
B
End Plate
