The Embedded I/O Company
TPMC316
Conduction Cooled
CAN Bus PMC Module
Version 1.0
User Manual
Issue 1.0.5
February 2010
TEWS TECHNOLOGIES GmbH
Am Bahnhof 7
25469 Halstenbek, Germany
Phone: +49 (0) 4101 4058 0
Fax: +49 (0) 4101 4058 19
e-mail:
info@tews.com
www.tews.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPMC316 and is the answer not in the manual?

Questions and answers

Related Manuals for Tews Technologies TPMC316

Summary of Contents for Tews Technologies TPMC316

  • Page 1 The Embedded I/O Company TPMC316 Conduction Cooled CAN Bus PMC Module Version 1.0 User Manual Issue 1.0.5 February 2010 TEWS TECHNOLOGIES GmbH Am Bahnhof 7 25469 Halstenbek, Germany Phone: +49 (0) 4101 4058 0 Fax: +49 (0) 4101 4058 19 e-mail: info@tews.com www.tews.com...
  • Page 2 RS485 interface reserves the right to change the product described in this document at any time without notice. TEWS TECHNOLOGIES GmbH is not liable for any damage arising out of the application or use of the device described herein.
  • Page 3 New address TEWS LLC September 2006 (1) New Notation for User Manual and Engineering Documentation 1.0.5 February 2010 (2) Added Note for TPMC316-10 Min. Baud Rate in the Technical Specification Table TPMC316 User Manual Issue 1.0.5 Page 3 of 20...

  • Page 4: Table Of Contents

    5.2 Local Software Reset........................16 5.3 Big / Little Endian..........................17 INSTALLATION......................19 6.1 CAN bus Termination ........................19 6.2 Physical Interface..........................19 PIN ASSIGNMENT – I/O CONNECTOR ..............20 7.1 Mezzanine Card Connector P14 ....................20 TPMC316 User Manual Issue 1.0.5 Page 4 of 20...
  • Page 5 TABLE 4-1 : PCI9030 HEADER........................12 TABLE 4-2 : PCI9030 BASE ADDRESS USAGE ...................13 TABLE 4-3 : PCI9030 LOCAL CONFIGURATION REGISTER ..............14 TABLE 4-4 : CONFIGURATION EEPROM TPMC316-XX................15 TABLE 5-1 : INTERRUPT CONTROL/STATUS REGISTER (INTCSR; 0X4C)..........16 TABLE 5-2 : LOCAL BUS LITTLE/BIG ENDIAN .....................17 TABLE 7-1 : MEZZANINE P14 CONNECTOR ....................20...

  • Page 6: Product Description

    RS485 interface for each of the two channels. The bus line termination can be enabled or disabled for each channel by solder pads (disabled per default). The TPMC316 has no front panel. It uses P14 I/O connector with the same pin assignment as the TPMC816.

  • Page 7: Technical Specification

    On board 120 ohms, disabled per default Transfer Rate Up to 1 Mbps at bus line length of up to 40 m Minimum Baud Rate for the TPMC316-10 is 60 Kbps (TJA1050 CAN Transceiver Timeout Feature) Isolation CAN bus isolated by optocouplers and DC/DC converter for each...

  • Page 8: Local Space Addressing

    Table 3-1 : PCI9030 Local Space Configuration 3.2 Local Address Space 0 The complete register sets of the two CAN controllers of the TPMC316 are accessible in the memory space of the PMC module. Address range: PCI Base Address 2 for Local Address Space 0 + (0x0000 to 0x00FF)

  • Page 9: Can Controller Address Map

    Reserved 0x0090-0x009E Message 9 0x009F P1CONF 0x00A0-0x00AE Message A 0x00AF P2CONF 0x00B0-0x00BE Message B 0x00BF P1IN 0x00C0-0x00CE Message C 0x00CF P2IN 0x00D0-0x00DE Message D 0x00DF P1OUT 0x00E0-0x00EE Message E 0x00EF P2OUT TPMC316 User Manual Issue 1.0.5 Page 9 of 20...

  • Page 10: Table 3-2 : Memory Address Map Can Controller Channel 0 Canch0

    Reserved 0x0170-0x017E Message 7 0x017F Reserved 0x0180-0x018E Message 8 0x018F Reserved 0x0190-0x019E Message 9 0x019F P1CONF 0x01A0-0x01AE Message A 0x01AF P2CONF 0x01B0-0x01BE Message B 0x01BF P1IN 0x01C0-0x01CE Message C 0x01CF P2IN TPMC316 User Manual Issue 1.0.5 Page 10 of 20...

  • Page 11: Table 3-3 : Memory Address Map Can Controller Channel 1 Canch1

    Address Description 0x01D0-0x01DE Message D 0x01DF P1OUT 0x01E0-0x01EE Message E 0x01EF P2OUT 0x01F0-0x01FE Message F 0x01FF Serial Reset Address Table 3-3 : Memory Address Map CAN Controller Channel 1 CANCH1 TPMC316 User Manual Issue 1.0.5 Page 11 of 20...

  • Page 12: Pci9030 Target Chip

    HS Nxt Cap. HS Cap. ID Y[23:16] 00 00 0000 0x4C VPD Address VPD Nxt Cap. VPD Cap. ID Y[31:16] 0000 00 03 0x50 VPD Data 00000000 Table 4-1 : PCI9030 Header TPMC316 User Manual Issue 1.0.5 Page 12 of 20...

  • Page 13: Pci Base Address Initialization

    Used 0x14 PCI9030 LCR’s I/O Used 0x18 PCI9030 Local Space 0 Used 0x1C PCI9030 Local Space 1 Not used 0x30 Expansion ROM Not used Table 4-2 : PCI9030 Base Address Usage TPMC316 User Manual Issue 1.0.5 Page 13 of 20...

  • Page 14: Local Configuration Register (Lcr)

    0x026DB6D2 All pins are outputs 0x70 Hidden1 Power Management data 0x00000000 Not used select 0x74 Hidden 2 Power Management data 0x00000000 Not used scale Table 4-3 : PCI9030 Local Configuration Register TPMC316 User Manual Issue 1.0.5 Page 14 of 20...

  • Page 15: Configuration Eeprom

    0xFFFF 0xFFFF 0xFFFF 0xFFFF 0xFFFF 0xFFFF 0xFFFF 0xFFFF 0xF0 0xFFFF 0xFFFF 0xFFFF 0xFFFF 0xFFFF 0xFFFF 0xFFFF 0xFFFF Table 4-4 : Configuration EEPROM TPMC316-xx Subsystem-ID Value (Offset 0x0C): TPMC316-10 0x000A TPMC316-11 0x000B TPMC316 User Manual Issue 1.0.5 Page 15 of 20...

  • Page 16: Configuration Hints

    PCI9030 remains in this reset condition until the PCI Host clears this bit. The contents of the PCI9030 PCI and Local Configuration Registers are not reset. The PCI9030 PCI Interface is not reset. TPMC316 User Manual Issue 1.0.5 Page 16 of 20...

  • Page 17: Big / Little Endian

    24 of the according register sets the mode. A value of 1 indicates Big Endian and a value of 0 indicates Little Endian. For further information please refer to the PCI9030 manual which is also part of the TPMC316-ED Engineering Documentation.
  • Page 18 0x34 Local Address Space 0 Bus Region Description Register EROMBRD 0x38 Expansion ROM Bus Region Description Register You could also use the PCI - Base Address 1 I/O Mapped Configuration Registers. TPMC316 User Manual Issue 1.0.5 Page 18 of 20...

  • Page 19: Installation

    CAN bus channel 1 active. Figure 6-1 : Soldering Connection Location LB1 – LB2 6.2 Physical Interface The TPMC316-10 provides a CAN High Speed interface and the TPMC316-11 a modified RS485 interface. TPMC316 User Manual Issue 1.0.5...

  • Page 20: Pin Assignment - I/O Connector

    Low level CAN voltage input/output channel 1 CAN High Speed or modified RS485 High level CAN voltage input/output channel 1 CAN High Speed or modified RS485 Ground channel 1 16…32 Table 7-1 : Mezzanine P14 Connector TPMC316 User Manual Issue 1.0.5 Page 20 of 20...

This manual is also suitable for:

Tpmc316-10Tpmc316-11

Table of Contents
