Never fill the tank in enclosed spaces, such as
basements or sheds.
There is a risk of poisoning and explosion!
9. Avoid skin contact with petrol.
10. Do not eat or drink, while you are refuelling the
machine. If you have swallowed petrol or oil, or if petrol
or oil has got into your eyes, then seek the advice of a
doctor immediately.
11. Close the tank lid immediately after filling the tank.
Make sure that it is properly closed.
12. Never use the machine without an air filter.
RESIDUAL RISKS
Even if you are operating this machine in accordance
with the provisions, residual risks will always still
remain. The following dangers can arise in connection
with the structure and design of this machine:
1. Health defects resulting from vibration emission if the
machine is being used over longer period of time or not
adequately managed and properly maintained.
2. Injuries and damage to property to due to broken
accessories or hidden objects that are suddenly dashed.
3. Injuries and damage to property to due to thrown
objects.
4. Burns, if touching hot surfaces.
EMERGENCY
Familiarise yourself with the use of this machine by
means of this instruction manual. Memorise the safety
directions and follow them to the letter. This
will help to prevent risks and hazards.
1. Be alert when using this machine, so that you can
recognise and handle risks early. Fast intervention can
prevent serious injury and damage to property.
2. Stop the engine and unplug the spark plug connector
if there's malfunctions. Have the machine checked by a
qualified professional and repaired, if necessary, before
you put it into operation again.
3. In case of fire stop the engine and unplug the spark
plug connector.
Immediately use fire-extinguishing measures, if the
switch of the machine is no longer accessible.
Warnings! Never use water to extinguish a
machine on fire.
Burning fuel must be extinguished with
special extinguishing agents. We recommend that
8
you keep a suitable fire extinguisher within reach
in your work area!
VIBRATION AND NOISE REDUCTION
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimize the
vibration and noise exposure risks:
1. Only use the machine as intended by its design and
these instructions.
2. Ensure that the machine is in good condition and well
maintained.
3. Use correct application tools for the machine and
ensure they in good condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this machine in accordance with these
instructions and keep it well lubricated (where
appropriate).
6. Plan your work schedule to spread any high vibration
tool use across a number of days.

4. Parts List

1. Handle
2. Guide handle
3. Ignition switch
4. Hand throttle
5. Choke lever
6. Air filter
7. Petrol tank
8. Exhaust pipe protection
9. Injector
10. String protection hood
11. String head
12. Cutting string
13. Guiding bar
14. Spark plug wrench
15. Allen keys
16. Safety push button
17. Screw driver
18. Oil/petrol mixing bottle
19.
Funnel
