Passive Components for RS-485 Networks
Mechanical Conditions
Oscillation
operation
Shock
operation
Construction
Dimensions (W x H x D) in mm
Tap line length
Weight
(incl. 1.5 m connecting cable)
Degree of protection
Test Marks
4-62
Tested to DIN IEC 68-2-6
10 to 58 Hz; amplitude 0.075 mm
58 to 500 Hz; acceleration 9.8 m/s
tested to DIN IEC 68-2-27
2
Half sine: 100 m/s , 16 ms
50 x 135 x 47
1.5 m
approx. 350 g
IP20
CE, UL, CSA
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
