  • Page 1 Druckmessumformer Pressure Transmitter Transmetteur de Pression HDA 4100 Absolutdruck Absolute pressure Pression absolue HDA 4300 Relativdruck Relative pressure Pression relative Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 2: Table Of Contents

    TECHNICAL DATA ..................14 GENERALITES ................... 15 MONTAGE ....................15 ENCOMBREMENTS ................... 16 ACCESSOIRES RACCORDEMENT ÉLECTRIQUE ........17 RACCORDEMENT ELECTRIQUE .............. 18 BRANCHEMENTS ..................18 CODE DE COMMANDE ................19 CARACTERISTIQUES TECHINQUES ............20 Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 3: Allgemeines

    Der Kabelschirm ist in Abhängigkeit der Umgebungsbedingungen fachmännisch und zum Zweck • der Störunterdrückung einzusetzen Direkte Nähe zu Verbindungsleitungen von Leistungsverbrauchern oder störenden Elektro- oder • Elektronikgeräten ist möglichst zu vermeiden Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 4: Abmessungen

    HDA 4100 / HDA 4300 ABMESSUNGEN HDA 4144 / 4344 Abbildung mit ZBE 03 Maß mit Winkeldose ZBE 03: 106 mm Maß mit Kupplungsdose ZBE 02: ≈ 125 mm HDA 4145 / 4345 Abbildung mit ZBE 01 HDA 4146 / 4346 Abbildung mit ZBE 06 G1/2 B DIN-EN 837 Stand: 16.12.2013...
  • Page 5: Elektrisches Zubehör

    ELEKTRISCHES ZUBEHÖR ZBE 03 Kupplungsdose 4-pol., abgewinkelt Binder Serie 714M18 ZBE 01 Kupplungsdose 3-pol.+PE, abgewinkelt EN 175301-803/ISO 4400(DIN 43650) ZBE 06 Kupplungsdose 4.polig, abgewinkelt M12x1 ZBE 02 Kupplungsdose 4-pol. Binder Serie 714M18 Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 6: Anschlussbilder

    HDA 43X6-A Pin 1 Pin 2 Pin 3 Pin 4 HDA 41X6-B HDA 41X4-A n.c. Signal n.c. Signal+ Signal- n.c. HDA 43X6-B HDA 43X4-A HDA 41X4-B Signal n.c. HDA 43X4-B Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 7: Bestellangaben

    F = FPM Dichtung (z.B. für Hydrauliköle) E = EPDM Dichtung (z.B. für Kältemittel) Anschlussmaterial (medienberührend) 1 = Edelstahl Anmerkung: Bei Geräten mit anderer Modifikationsnummer ist das Typenschild bzw. die mitgelieferte technische Änderungsbeschreibung zu beachten. Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 8: Technische Daten

    -25° C mit FPM- oder EPDM Dichtung, -40° C auf Anfrage Die Angaben in diesem Prospekt beziehen sich auf die beschriebenen Betriebsbedingungen und Einsatzfälle. Bei abweichenden Einsatzfällen und/oder Betriebsbedingungen wenden Sie sich bitte an die entsprechende Fachabteilung. Technische Änderungen sind vorbehalten. Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 9: General

    The cable screening must be fitted by qualified personnel subject to the ambient conditions and with • the aim of suppressing interference Direct proximity to connecting lines of user units or electrical or electronic units causing interference • must be avoided as far as possible Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 10: Dimensions

    HDA 4100 / HDA 4300 DIMENSIONS HDA 4144 / 4344, shown with ZBE 03 Dimension with right-angled plug ZBE 03: 106 mm Dimension with straight plug ZBE 02: ≈ 125 mm HDA 4145 / 4345, shown with ZBE 01 HDA 4146 / 4346, shown with ZBE 06 G1/2 B DIN EN 837 Stand: 16.12.2013...
  • Page 11: Electrical Accessories

    ZBE 03 Binder connector, right angled, EN 175301-803/ISO 4400 (DIN 43650) 4-pole series 714 M18 sealing gasket ZBE 02 Binder connector, ZBE 06 M12x1 connector, right angled, 4-pole series 714 M18 4-pole Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 12: Connection Diagrams

    HDA 41X6-B HDA 41X4 frei Signal HDA 43X6-B HDA 43X4 Pin 1 Pin 2 Pin 3 Pin 4 HDA 41X4-A n.c. Signal+ Signal- n.c. HDA 43X4-A HDA 41X4-B Signal n.c. HDA 43X4-B Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 13: Model Code

    = EPDM seal (e.g. for refrigerants) Material, mechanical connection (in contact with medium) = stainless steel Note: On units with other modification numbers, please read the label or the technical amendment details supplied with the number. Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 14: Technical Data

    -25° C with FPM oe EPDM seal, -40° C on request The information in this brochure relates to the operating conditions and applications described. For applications or operating conditions not described, please contact the relevant technical department. Subject to technical modifications. Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 15: Generalites

    L'utilisation du câble blindé se fait en fonction de l'environnement. Il est utilisé de façon à diminuer • les perturbations ; Eviter, si possible, de placer à proximité des raccordements des appareils électriques ou • électroniques. Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 16: Encombrements

    HDA 4100 / HDA 4300 ENCOMBREMENTS HDA 4144 / 4344, avec ZBE 03 Dimension avec connecteur coudé ZBE 03: 106 mm Dimension avec connecteur droit ZBE 02: ≈ 125 mm HDA 4145 / 4345, avec ZBE 01 HDA 4146 / 4346, avec ZBE 06 G1/2 B DIN EN 837 Stand: 16.12.2013...
  • Page 17: Accessoires Raccordement Électrique

    ZBE 01 Connecteur coudé 3 pôles + terre ZBE 03 Connecteur coudé EN 175301-803/ISO 4400(DIN 43650) 4 pôles BINDER , série 714M18 ZBE 02 Connecteur droit ZBE 06 Connecteur coudé 4 pôles BINDER, série 714M18 M12x1, 4 pôles Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 18: Raccordement Electrique

    Binder connecteur 714M18 frei Signal HDA 43X6-B HDA 41X4 HDA 43X4 Pin 1 Pin 2 Pin 3 Pin 4 HDA 41X4-A n.c. Signal+ Signal- n.c. HDA 43X4-A HDA 41X4-B Signal n.c. HDA 43X4-B Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 19: Code De Commande

    = joint EPDM (p. ex. pour fluids de refroidissement) Matériau de raccordement (en contact avec le fluide) = acier inoxydable Attention: Pour les appareils avec d'autres indices de modification, veuillez respecter la plaque signalétique ou le descriptive technique. Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
  • Page 20: Caracteristiques Techinques

    Les données de ce prospectus se réfèrent aux conditions de fonctionnement et d'utilisation décrites. Pour des conditions d'utilisation et de fonctionnement différentes, veuillez vous adresser au service technique compétent. Sous réserve de modifications techniques. Stand: 16.12.2013 HYDAC ELECTRONIC GMBH Mat. Nr.: 669687 D/E/F...
