- Page 1 Vista DP 1×4 KVM Switch • DisplayPort 4K@30 • USB2.0 • Audio Installation Operation Manual 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 techsupport@rose.com...
- Page 2 Vista DP KVM Switch to be in good working order for one year from the date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or replace the Unit as set forth below.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Contents Disclaimer System Introduction Features Package Contents Additional Items that may be required Vista DP Models Installing the Vista DP Switch Rackmount Kit: Operation Controlling the Vista DP Front Panel Control Hotkey Commands Control using the RS-232 port Establish a connection to the Vista DP switch EDID Learning and Programming (HDMI Model Only) Safety... -
Page 4: Disclaimer
(See limited warranty). System Introduction Thank you for choosing the Vista DP. It is the result of Rose Electronics commitment to providing state-of-the- art solutions for today’s demanding workplace. a dedicated multi-platform KVM switch. It is capable of managing up to four 4K computers through a single managing computer. -
Page 5: Package Contents
USB Type A to USB Type B M/M cable ■ DisplayPort to DisplayPort M/M cable ■ HDMI to HDMI M/M cable ■ Stereo 3.5mm audio M/M cable ■ Serial DB9 M/F cable These cables can be ordered separately from Rose Electronics. Vista DP KVM Switch Manual... -
Page 6: Vista Dp Models
MODELS Vista DP Models The Vista DP is offered in two models – one with a DisplayPort output, and the other with a HDMI output. Front Panel Rear Panel Figure 1. Vista DP with DisplayPort Output Front Panel Rear Panel Figure 2. -
Page 7: Installing The Vista Dp Switch
Installing the Vista DP Switch Installation of the Vista DP is very simple. Figure 3. Vista DP cabling layout diagram 1. Ensure that power is disconnected from the Vista DP. 2. Connect the DisplayPort cables and USB cables (male-A to male-B) from the computers to the respective ports on the Vista DP. -
Page 8: Operation
Operation Controlling the Vista DP The computers on the Vista DP can be switched using the buttons on the Front Panel, through keyboard hot- key commands, or RS-232 commands. The video, keyboard, and mouse can all be switched simultaneously or independently of each other. -
Page 9: Control Using The Rs-232 Port
Control using the RS-232 port Controlling the Vista DP via RS-232 requires an RS-232 card installed on your computer or a USB to RS-232 adapter. Below are instructions on how to create an RS-232 connection between a PC and the Vista DP switch Use a terminal client software to connect the host PC or notebook to the switch. -
Page 10: Edid Learning And Programming (Hdmi Model Only)
If you are using a USB to COM port adapter on a Windows PC and need to identify the COM port used, do the following: 1. Click on the Windows Start button. 2. Click on Control Panel. 3. Click on Device Manager. 4. -
Page 11: Safety
Safety The Vista DP KVM Switch, like all electronic equipment, should be used with care. To protect yourself from possible injury and to minimize the risk of damage to the Unit, read and follow these safety instructions. Follow all instructions and warnings marked on this Unit. ... -
Page 12: Maintenance And Repair
This Unit does not contain any internal user-serviceable parts. In the event a Unit needs repair or maintenance, you must first obtain a Return Authorization (RA) number from Rose Electronics or an authorized repair center. This Return Authorization number must appear on the outside of the shipping container. -
Page 13: Appendices
APPENDICES Appendix A — Specifications Chassis Dimensions (W x D x H) and Weight DisplayPort Model: 12.75 x 2 x 6 inches / 324 x 51 x 153 mm Dimensions HDMI Model: 12.75 x 2 x 5.75 inches / 324 x 51 x 146 mm DisplayPort Model: 3.75 lbs / 1.70 Kg Weight HDMI Model: 3.55 lbs / 1.61 Kg... - Page 14 ▪ ▪ WWW.ROSE.COM sales@rose.com (800) 333-9343 ▪ ▪ Rose Electronics 10707 Stancliff Road Houston, Texas 77099 Rose USA (281) 933-7673 ▪ Rose Europe +49 (0) 2454 969442 ▪ Rose Asia +65 6324 2322 Rose Australia +61 (0) 421 247083 WWW.ROSE.COM...
