- Page 1 MultiVideo DP 1×4 Multi-head KVM Switch • DisplayPort • USB2.0 • Audio Installation Operation Manual 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 techsupport@rose.com...
- Page 2 MultiVideo DP KVM Switch to be in good working order for one year from the date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or replace the Unit as set forth below.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Contents Disclaimer System Introduction Features Package Contents Additional Items that may be required MultiVideo DP Models Installing the MultiVideo DP Switch Operation Controlling the Multivideo DP Front Panel Control Hotkey Commands Control using the RS-232 port Establish a connection to the Multivideo DP switch EDID Learning and Programming (HDMI Model Only) Safety Maintenance and Repair... -
Page 4: Disclaimer
(See limited warranty). System Introduction Thank you for choosing the MultiVideo DP. It is the result of Rose Electronics commitment to providing state- of-the-art solutions for today’s demanding workplace. It is capable of switching up to four dual-head or quad- head DisplayPort computers through a single user console. -
Page 5: Package Contents
USB Type A to USB Type B M/M cable ■ DisplayPort to DisplayPort M/M cable ■ HDMI to HDMI M/M cable ■ Stereo 3,5mm audio M/M cable ■ Serial DB9 M/F cable These cables can be ordered separately from Rose Electronics. MultiVideo DP KVM Switch Manual... -
Page 6: Multivideo Dp Models
MODELS MultiVideo DP Models The MultiVideo DP comes as a dual-head or quad-head KVM switch. Each is offered in two models – one with a DisplayPort output, and the other with a HDMI output. Figure 1. MultiVideo DP Dual Front Panel Figure 2. -
Page 7: Figure 4. Multivideo Dp Quad Front Panel
Figure 4. MultiVideo DP Quad Front Panel Figure 5. MultiVideo DP Quad with DisplayPort Output Rear Panel Figure 6. MultiVideo DP Quad with HDMI Output Rear Panel MultiVideo DP KVM Switch Manual... -
Page 8: Installing The Multivideo Dp Switch
Installing the MultiVideo DP Switch Installation of the MultiVideo DP is very simple. Figure 7. MultiVideo DP Dual typical application Ensure that power is disconnected from MultiVideo DP. 1. Connect DisplayPort cables and USB type A to type B cables between each computer and its respective ports on the MultiVideo DP. -
Page 9: Operation
Operation Controlling the Multivideo DP The computers on the Multivideo DP can be switched using the buttons on the Front Panel, through keyboard hot-key commands, or RS-232 commands. The video, keyboard, and mouse can all be switched simultaneously or independently of each other. Each of these is described below. Front Panel Control To switch ports using the front panel, press the ▲... -
Page 10: Control Using The Rs-232 Port
Control using the RS-232 port Controlling the Multivideo DP via RS-232 requires an RS-232 card installed on your computer or a USB to RS- 232 adapter. Below are instructions on how to create an RS-232 connection between a PC and the Multivideo DP switch Use a terminal client software to connect the host PC or notebook to the switch. -
Page 11: Edid Learning And Programming (Hdmi Model Only)
If you are using a USB to COM port adapter on a Windows PC and need to identify the COM port used, do the following: 5. Click on the Windows Start button. 6. Click on Control Panel. 7. Click on Device Manager. 8. -
Page 12: Safety
Safety The MultiVideo DP KVM Switch, like all electronic equipment, should be used with care. To protect yourself from possible injury and to minimize the risk of damage to the Unit, read and follow these safety instructions. Follow all instructions and warnings marked on this Unit. ... -
Page 13: Maintenance And Repair
This Unit does not contain any internal user-serviceable parts. In the event a Unit needs repair or maintenance, you must first obtain a Return Authorization (RA) number from Rose Electronics or an authorized repair center. This Return Authorization number must appear on the outside of the shipping container. -
Page 14: Appendices
APPENDICES Appendix A — Specifications Chassis Dimensions (W x D x H) and Weight Dimensions Dual-Head 12.8" x 6.0" x 3.0" (325mm x 152mm x 76mm) Quad-Head 12.8" x 6.0" x 4.5" (325mm x 152mm x 114mm) Weight Dual-Head 4.4 lbs. (2.0 Kg) Quad Head 5.7 lbs. -
Page 15: Appendix B - Part Numbers
APPENDICES Appendix B — Part Numbers Part Numbers Description MDM-4T2DP-A1 1X4 KVM Switch, Dual-head, DP output MDM-4T4DP-A1 1X4 KVM Switch, Quad-head, DP output MDM-4T2DPH-A1 1X4 KVM Switch, Dual-head, HDMI out MDM-4T4DPH-A1 1X4 KVM Switch, Quad-head, HDMI out CAB-DPMM006 DisplayPort cable, M/M, 6ft (20m) CAB-HDMIMM006 HDMI cable, M/M, 6ft (2.0m) CAB-USBMM006... - Page 16 ▪ ▪ WWW.ROSE.COM sales@rose.com (800) 333-9343 ▪ ▪ Rose Electronics 10707 Stancliff Road Houston, Texas 77099 Rose USA (281) 933-7673 ▪ Rose Europe +49 (0) 2454 969442 ▪ Rose Asia +65 6324 2322 Rose Australia +61 (0) 421 247083 WWW.ROSE.COM...
