Model P4R User Guide
P4R Receiver
®
for use with the PSM
400 Wireless Personal Monitor System
2005, Shure Incorporated
Printed in U.S.A.
©
27D8711 (Rev. 5) Patent Des. 442,938

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P4R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shure P4R

Summary of Contents for Shure P4R

  • Page 1 Model P4R User Guide P4R Receiver ® for use with the PSM 400 Wireless Personal Monitor System 2005, Shure Incorporated Printed in U.S.A. © 27D8711 (Rev. 5) Patent Des. 442,938...
  • Page 2 USING THIS SYSTEM AT EXCESSIVE VOLUMES CAN CAUSE PERMANENT HEARING DAMAGE. USE AS LOW A VOLUME AS POSSIBLE. In order to use this system safely, avoid prolonged listening at excessive sound pressure lev- els. Please use the following guidelines established by the Occupational Safety Health Ad- ministration (OSHA) on maximum time exposure to sound pressure levels before hearing damage occurs.

  • Page 3: Quick Setup

    Set up and activate a P4T transmitter according to directions in the P4T user's guide. Open the battery door of the P4R receiver and insert a 9V alkaline battery, following the correct +/- alignment. See Battery Installation on page 4.

  • Page 4: Battery Installation

    SCROLL and SELECT pushbuttons (see Pushbutton Controls on page 6). FIGURE 3 1. RF: Indicates the P4R receiver is receiv- ing a transmission. Always check for RF reception prior to inserting earphones into ears.
  • Page 5 MixMode combines these two signals into one monitor mix and allows you to control this mix during the performance with the P4R receiver. For example, if the band over- powers the vocals in the mix, increase the level of the vocals and decrease the level of the band by simply adjusting the balance knob.

  • Page 6: Pushbutton Controls

    3. Push the SCROLL pushbutton to confirm changes. LOCKING OUT THE LCD SCREEN Once the P4R's functions are set for use, lock out the LCD screen and pushbuttons to prevent un- wanted changes during or between performances. Use the following instructions to lock out the front panel: 1.

  • Page 7: Specifications

    SHURE FOR HOME OR OFFICE USE LICENSING Changes or modifications not expressly ap- proved by Shure Incorporated could void your authority to operate the equipment. Licensing of Shure wireless microphone equipment is the user's responsibility, and licensability de- pends on the user's classification and applica- tion, and on the selected frequency.
  • Page 8 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 9 United States, Canada, Latin America, Caribbean: 5800 W. Touhy Avenue, Niles, IL 60714-4608, U.S.A. Phone: 847-600-2000 U.S. Fax: 847-600-1212 Intl Fax: 847-600-6446 Europe, Middle East, Africa: Shure Europe GmbH, Phone: 49-7131-72140 Fax: 49-7131-721414 Asia, Pacific: Shure Asia Limited, Phone: 852-2893-4290 Fax: 852-2893-4055...
