  • Page 1 DC-B Series Installation Manual DC-V3213XJ-4.3mm DC-V3213XJ-2.5mm Powered by...
  • Page 2 Before reading this manual This is a basic installation manual for use of an IDIS camera module and a main unit. Users who are using this product for the first time, as well as users with experience using comparable products, must read this manual carefully before use and heed to the warnings and precautions contained herein while using the product.
  • Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
  • Page 4 IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice for reasons such as functionality enhancements.

  • Page 5: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 6 Product Features .

  • Page 6: Part 1 - Introduction

    • BLC, HLC, WDR for improved video quality in high- to manage multiple network cameras. In addition, the contrast situations embedded web server (IDIS Web) lets you remotely view live video or scan recorded video using a web browser. • Day & Night feature Alternatively, you can use the provided remote access •...

  • Page 7: Accessories

    Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. DC-V3213XJ-4.3mm DC-V3213XJ-2.5mm Main Unit Camera Module Rubber Foot (4ea.) Screws (each 2ea.) Quick Guide...

  • Page 8: Overview

    Part 1 – Introduction Overview • Lens Sharp-corn Type or Board Type lens is installed. • Mount Bracket Product color and design may vary depending on the This bracket can be installed to fix the camera. Use model. 1/4–20 UNC (20-thread), 2.5mm +/- 0.2mm (ISO standard) or 0.197 (ASA standard) screws to attach the mount.
  • Page 9 Part 1 – Introduction • Status LED • Video In - Power LED: Indicates the system's operating Connect the camera cable. Connect a Cat5e cable status. For more information, refer to the LED with an RJ-45 connector to the camera mudule. Status Indications.
  • Page 10 It's also possible to do a factory reset by pressing and releasing the reset switch while the camera is turned on or using the IDIS Discovery program from a remote location. A factory reset will reboot the system. For more information on factory reset, refer to the IDIS Discovery operation manual.

  • Page 11: Installation

    Part 1 – Introduction Power Connector The table below shows the network cable specifications. <The network cable specifications> Item Content Note Connector RJ-45 10/100 Ethernet 10/100 Base Mbps Cable UTP Category 5e Maximum 100m length DC12V + Power connection IEEE 802.3at, Class 4 I/O Connector •...

  • Page 12: Inserting A Sd Memory Card

    Part 1 – Introduction Inserting a SD Memory Card Adjust the angle of the camera module. Use the screws to secure the main unit on a wall or Pull and lift the cover to open. a ceiling. Insert a SD memory card into the SD memory card slot with the 'micro SD' print facing upward.

  • Page 13: Dimensions

    Part 1 – Introduction Dimensions DC-V3213XJ-2.5mm - Side DC-V3213XJ-4.3mm - Front 30mm 30mm (1.18") 55mm DC-V3213XJ-4.3mm - Side 45mm (1.77") Main Unit - Front 30mm (1.18") 153mm 45mm (1.77") Main Unit - Side DC-V3213XJ-2.5mm - Front 132.7mm 153mm...

  • Page 14: Part 2 - Camera Connection

    Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Audio In Audio Out Power Alarm Out Sensor In Main Unit Camera Module...

  • Page 15: With Non Directip™ Nvr-Based Layout

    Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP™ NVR connection or VMS connection such as IDIS Solution Suite Compact.

  • Page 16: Part 3 - Appendix

    ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 8.0 or below.

  • Page 17: Specifications

    Part 3 - Appendix Specifications These product specifications may change without prior notice. Camera Module Image Sensor 1/2.9" CMOS Max. Resolution 1920 x 1080 @30fps Scanning Mode Progressive Scan Lens type Sharp-corn / Board Focal Length f=4.3mm / f=2.5mm Aperture F=2.0 Angular Field of View 95°(D) x 83°(H) x 47°(V) (4.3mm)
  • Page 18 Part 3 - Appendix Multi-Video DirectIP Quadruple Streaming Non DirectIP Quadruple Ethernet RJ45(10/100BASE-T) Main Unit Audio In/Out Line-in 1ea / Line-out 1ea Alarm In 1 TTL, NC/NO Programmable, 2.4V(NC) or 0.3V(NO) threshold, 5V DC, terminal block Alarm Out 1 relay out, 0.25A @ 250Vac, 1A @ 30Vdc, terminal block Video In 1 RJ45 (HD-TVI) Edge Storage** (Optional)
