- Page 1 DirectCX Camera Installation Manual TC-B5501X TC-B5501XP TC-B5502X...
- Page 2 Before reading this manual This is a basic installation manual for use of an IDIS camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this manual carefully before use and heed to the warnings and precautions contained herein while using the product.
- Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
- Page 4 IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice for reasons such as functionality enhancements.
-
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
Part 1 – Introduction Product Features TC-B5501X/ TC-B5501XP/ TC-B5502X is an analog camera that transmits video over coaxial. • Support for DC 12V and PoC (Power over Coaxial), and AC 24V Power support for each model - see product specifications on the back page •... -
Page 7: Accessories
Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. Camera C-Mount Ring Installation Parts Protective Cover (attaches to camera) Quick Guide... -
Page 8: Overview
Part 1 – Introduction Overview • Mount Bracket Installation Hole This bracket can be installed on either top or bottom of the camera. Use 1/4–20 UNC (20-thread), 2.5mm +/- 0.2mm (ISO standard), or 0.197 (ASA standard) Product color and design may vary depending on the standard screw. -
Page 9: Rear
Part 1 – Introduction Rear TC-B5501XP TC-B5501X Power LED BNC Video Out Power (DC 12V) OSD button Power LED • Power LED BNC Video Out Displays the system operating status. OSD button • BNC Video Out Connect to the PoC Power unit •... - Page 10 Part 1 – Introduction TC-B5502X The following table describes the coaxial cable specifications. <The coaxial cable specifications> Item Content Note Connector Cable 3C-2V 5C-2V Maximum 300m 500m Length The Power LED Status Indication Description LED Status No connection Power Connection Power (DC 12V / AC 24V) You can change the video output format by using the Power LED...
-
Page 11: Installation
Part 1 – Introduction Installation C-Mount Lens The lens must be purchased separately. If you'd like to purchase a lens, contact your camera retailer. This camera supports manual iris lenses and DC type auto iris lenses, it can be mounted with CS-mount or C-mount type when connect to the camera. -
Page 12: Dimensions
Part 1 – Introduction Dimensions Front 74mm 60mm 74mm 60mm 121.8mm Side 121.8mm... -
Page 13: Part 2 - Camera Connection
Part 2 - Camera Connection DirectCX DVR Layout TC-B5501X / TC-B5502X TVI Camera Power VGA Monitor Out Network HDMI Monitor Out iRAS Remote Monitoring... - Page 14 Part 2 - Camera Connection TC-B5501XP PoC Power Unit TVI Camera Power VGA Monitor Out Network HDMI Monitor Out iRAS Remote Monitoring...
-
Page 15: Part 3 - Appendix
Part 3 - Appendix Troubleshooting Problem Check The main unit won't turn • Check the power cable connection. If using the PoC power, check the connection of the coaxial cable. • Check the power outlet. If using the PoC power, check the device power. I can't see Live videos. -
Page 16: Specifications
Part 3 - Appendix Specifications These product specifications may change without prior notice. Camera Image Sensor 1/2.8" CMOS Max. Resolution 2592x1944 Scanning Mode Progressive Scan Lens type Optional (CS/C-Mount) Iris Control Manual iris, DC type auto iris (megapixel recommended) Min. Illumination COLOR : 0.12Lux @ F 1.3 B&W : 0.06Lux @F 1.3 Dynamic Range... - Page 17 Part 3 - Appendix Power TC-B5501X Maximum 1.8W Consumption TC-B5501XP Maximum 3.2W TC-B5502X DC 12V, Maximum 3.1W AC 24V, Maximum 3.7W Approval FCC, CE No FCC CE certification for TC-B5501XP External Dimensions (W x H 74mm x 60mm x 121.9mm (2.91" x 2.36" x 4.79") x D) Weight (Main TC-B5501X/...
- Page 18 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
