- Page 1 DirectCX Camera Installation Manual TC-T5531WRX TC-T5531WRXP TC-T5532WRX...
- Page 2 Before reading this manual This is a basic installation manual for use of an IDIS camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this manual carefully before use and heed to the warnings and precautions contained herein while using the product.
- Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
- Page 4 IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice for reasons such as functionality enhancements.
-
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
Part 1 – Introduction Product Features TC-T5531WRX/TC-T5531WRXP/TC-T5532WRX is an analog camera that tranmits video over coaxial. • Supports DC 12V, AC 24V and PoC (Power over Coaxial) Power source for each model —see product specifications on the back page. • TVI /AHD /SD video output support. •... -
Page 7: Accessories
Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. Camera Quick Guide Bushings (4 ea.) Camera Sun Shield Sun Shield Screw Screws (4 ea.) -
Page 8: Overview
Part 1 – Introduction Overview Product color and design may vary depending on the model. Body • Lens Motorized focus and zoom lens is installed. • IR LED A sensor in the bottom middle monitors lighting levels and activates the IR LED during low-lighting conditions. -
Page 9: I/O Device Port
Part 1 – Introduction I/O Device Port The following table describes the DC 12V, AC 24V, and coaxial cable specifications. TC-T5531WRX / TC-T5532WRX <DC 12V cable specifications> Cable Type (AWG) TC-T5531 Maximum WRX/WRXP length TC-T5532 <AC 24V cable specifications> Cable Type (AWG) Power In (DC 12V / AC 24V) TC-T5532 Maximum... -
Page 10: Installation
Part 1 – Introduction Installation Angle Adjustment Installation of this product does not require the use of special tools. For more information on other devices comprising the overall system, refer to their respective installation manuals. Product color and design may vary depending on the model. -
Page 11: Dimensions
Part 1 – Introduction Dimensions 104mm 59mm 19.6mm 217mm 20mm 75mm 80mm... -
Page 12: Part 2 - Camera Connection
Part 2 - Camera Connection DirectCX DVR Layout TC-T5531WRX TVI Camera Power VGA Monitor Out Network HDMI Monitor Out iRAS Remote Monitoring... - Page 13 Part 2 - Camera Connection TC-T5531WRXP PoC Power Unit TVI Camera Power VGA Monitor Out Network HDMI Monitor Out iRAS Remote Monitoring...
-
Page 14: Part 3 - Appendix
Part 3 - Appendix Troubleshooting Problem Check The main unit won't turn • Check the power cable connection. If using the PoC power, check the connection of the coaxial cable. • Check the power outlet. If using the PoC power, check the device power. I can't see Live videos. -
Page 15: Specifications
Part 3 - Appendix Specifications These product specifications may change without prior notice. Camera Image Sensor 1/2.8" CMOS Max. Resolution 2592 x 1944 Scanning Mode Progressive Scan Lens type Motorized Vari-focal Focal Length f=3 - 13.5mm Aperture F1.4 - 3.2 Iris Control DC Iris Angular Field of... - Page 16 Part 3 - Appendix General Operating Temperature -10°C ~ 55°C (-50°F ~ +131°F) Operating Humidity 0% ~ 90% Power Source TC-T5531WRX DC 12V TC-T5531WRXP TC-T5532WRX DC 12V, AC 24V Power TC-T5531WRX Max. 6.6W Consumption TC-T5531WRXP Max.7.4W TC-T5532WRX DC 12V Max. 8W AC 24V Max.
