Blades
Attaching the Blades
To attach a power supply blade:
1.
Remove the power supply cover (not shown). To do this, slide the lock down and hold it while you lift off
the cover.
2.
Insert the latch on the blade into the notch on the power supply.
3.
Slide the lock down and hold it while you press the blade in place. Then, release it.
TM
MultiConnect
PCIe MTPCIE-H5/MTPCIE-BW Developer Guide
Power Supply with
EU blad
1 - Latch
2 - Notch
3 - Sliding lock
Power Supply with
NAM blade
PRODUCT OVERVIEW
Power Supply with
UK blade
7
