Bluetooth and Wi-Fi Antenna Cable Information
Use the following UFL to R-SMA RF cable to connect the device to the antenna.
Description:
Multi-Tech Part Number:
Multi-Tech ordering information:
Model
CARSMA-UFL-1
CARSMA-UFL-10
CARSMA-UFL-50
Average Cable Loss
The table shows the average cable loss for each cell band.
Band
2.4MHz

OEM Integration

Note: This device is for OEM integration only.
FCC and Industry Canada Information to End-users
FCC & IC Information to End-users The user manual for the end-users must contain the statements required by the
following FCC and IC regulations: 47 C.F.R. 15.19(a)(3), 15.21, 15.105 and RSS-Gen Issue 3, Dec 2010; 7.1.2 and
7.1.3
TM
MultiConnect PCIe MTPCIE-H5/MTPCIE-BW Developer Guide
Coax R-SMA to UFL 6 inch (152.4mm)
45009628L
Quantity
1
10
50
Loss
0.63
ANTENNAS, CABLES, GPS
