3G Antenna Requirements/Specifications
Category
Frequency Range
Impedance
VSWR
Typical Radiated Gain
Radiation
Polarization

Antenna Cable Information

Use the following UFL to SMA RF cable to connect the device to the antenna.
Description:
Multi-Tech Part Number:
Multi-Tech ordering information:
Model
CASMA-UFL-1
CASMA-UFL-10
CASMA-UFL-50
Average Cable Loss
The table shows the average cable loss for each cell band.
Band
800
TM
MultiConnect PCIe MTPCIE-H5/MTPCIE-BW Developer Guide
Description
824 – 960 MHz / 1710 – 1990 MHz / 1920 – 2170 MHz
50 Ohms
VSWR should not exceed 2.0:1 at any point across the bands of operation
850 MHz
950 MHz
1800 MHz
1900 MHz
2100 MHz
Omni-directional
Linear Vertical
Coax SMA to UFL 8.5inch (216mm)
45009575L
Quantity
1
10
50
Loss
0.37
3.17 dBi
3.51 dBi
3.55 dBi
3.0 dBi
3.93 dBi
