PRODUCT OVERVIEW

Product Overview

About MultiConnect PCIe

The MultiConnect™ PCIe embedded cellular modem is a complete, ready-to-integrate communications device that
offers standard-based penta-band HSPA+ 21, dual-band EV-DO Rev A, or CDMA performance. This quick-to-market
communications device allows developers to add wireless communication and GPS tracking to products with a
minimum of development time and expense. The MultiConnect PCIe embedded cellular modem is based on
industry-standard open interfaces and utilizes a PCI Express Mini Card form factor.

Documentation

The following documentation is available by email to oemsales@multitech.com or by using the Developer Guide
Request Form at www.multitech.com.
■ MultiConnect PCIe Developer Guide – This document. Provides an overview, safety and regulatory
information, design considerations, schematics, and device information for developers.
■
AT Command Guide – Device specific AT command reference guide.

Developer Kit Contents

Your Developer Kit (MTPCIE-DK1) includes the following:
Developer Board
Power Supply
Cables
Antennas
Customer Notices
Additional

Attaching Power Supply Blades

Power Supply and Blades

If your device shipped with a power cord, attach the blades for your region.
6
1 - MTPCIE-DK Developer Board
1 - 100-240V 9V-1.7A power supply with removable blades, 1 - US blade/plug, 1 - EURO
blade/plug, 1 - UK blade/plug
1 - RS-232 DB9F-DB9M serial cable, 1 - RJ-45 Ethernet cable, 2 -USB cable 2 - SMA-to-UFL
antenna cables (1 - for cellular, 1 - for GPS) 1 - RSMA-to-UFL antenna cable for
Bluetooth/Wi-Fi
1 - 3.3V magnetic GPS antenna , 1 - HEPTA band SMA antenna, 1 - 2.4GHz, dipole Wi-Fi
antenna
Modem activation notice
One promotional screwdriver
TM
MultiConnect PCIe MTPCIE-H5/MTPCIE-BW Developer Guide
