DEVELOPER BOARD AND SCHEMATICS

Board Components

Jumper
JP3, JP4, JP5, JP48
JP6
JP43, JP44
JP45
JP49
JP50
JP51, JP52
JP53, JP54
JP57, JP58
JP59, JP60, JP61,JP63,JP64, Selects serial connection for PCIe device. Pins 1 & 2 jumpered selects DB9 connector
JP69
JP65, JP66, JP67, JP68
JP70
JP73, JP74
JP75, JP76, JP77, JP78
JP79, JP80
JP81, J82
JP83, JP84
JP85
JP86
JP87
JP88
JP89
30
Description
Selects CGND or GND for antenna holder grounding. Default is CGND.
JP6 allows you to select either the internal 5V regulator (INT PWR) or to choose EXT
5V (EXT PWR). For the EXT PWR, you can use your own external 5V power source
and plug it into J11.
Not used by PCIe devices.
Board Power. Default is installed.
Probes for connecting speaker.
Probes for connecting microphone.
Debugging probes for PCIE connector J23.
Selects USB host connected to PCIe device. Pins 1 & 2 jumpered selects external USB
host connected to J4.
Selects USB host connected to quad serial UART U20. Pins 1 & 2 jumpered selects
external USB host connected to J24.
J1 connected to PCIe device. Pins 2 & 3 jumpered selects quad UART U20 connected
to PCIe device. All jumpers must be moved to the same position.
Selects serial connection for PCIe Bluetooth device. Pins 1 & 2 jumpered selects DB9
connector J14 connected to PCIe Bluetooth device. Pins 2 & 3 jumpered selects quad
UART U20 connected to PCIe Bluetooth device. All jumpers must be moved to the
same position.
Probes for PCIe GPIO2 & GPIO3. The pin next to the text "GPIO_3.3V" is GPIO3. The
center pin is GPIO2.
Not used by PCIe devices.
When these jumpers are installed, DVI interface of audio codec U84 is connected to
DVI interface of PCIe device. By removing these jumpers when connecting an
external DVI device.
Use these jumper pins to connect an external DVI device.
Selects source for programming audio codec U84. Pins 1 & 2 jumpered selects
MICRO U84 as source. Default is MICRO.
These pins can be used for programming MICRO U84.
Selects power source for MICRO U85. Default is 1.8v
May be used to manually reset PCIe Bluetooth device by briefly installing and then
removing a jumper. Default is no jumper installed.
Not applicable for this device.
May be used to manually reset PCIe Wi-Fi device by briefly installing and then
removing a jumper. Default is no jumper installed.
This jumper, when installed, connects power to PCIe device.
TM
MultiConnect
PCIe MTPCIE-H5/MTPCIE-BW Developer Guide
