Specifications

Monitor Specifications
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
DisplayPort: DisplayPort Connector:
USB-C Port:
HDMI: HDMI Connector:
Display Colors
Synchronization Range
Viewing Angle
Response Time
Active Display Area Landscape: Horiz.:
Portrait: Horiz.:
USB Hub
Load Current:
AUDIO
Audio Input: DisplayPort Connector:
HDMI Connector:
Headphone Output: STEREO Mini Jack:
Speakers Practical Audio Output:
ControlSync
(available up to 8 sub-monitors)
Power Supply
Current Rating
Dimensions
Stand adjustable range Height Adjustment:
Tilt / Pivot / Swivel:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
NOTE: Technical specifications are subject to change without notice.
MultiSync EA271U
Diagonal: 68.47 cm/27 inches
68.47 cm/27 inches
3840 x 2160
Digital RGB
Digital RGB
Digital YUV
Digital RGB
1,064,332,261 (DisplayPort/HDMI 10 bit)
Horizontal: 31.5 kHz to 135.0 kHz
Vertical: 30 Hz to 75 Hz
Left/Right: ±89° (CR > 10)
Up/Down: ±89° (CR > 10)
5 ms (Gray to Gray Typ.)
596.7 mm/23.5 inches
Vert.: 335.7 mm/13.2 inches
335.7 mm/13.2 inches
Vert.: 596.7 mm/23.5 inches
I/F: USB Specification Revision USB 3.1 Gen 1
Port: Upstream 2 (incl. 1 x USB-C Port)
Downstream 3
Downstream Port: 5V/0.9 A (Max.)
USB-C Port: 60 W (Max.) 5/9/12/15/20 V
Digital Audio
Digital Audio
1.0 W + 1.0 W
IN: Stereo Micro jack 2.5 φ
OUT: Stereo Micro jack 2.5 φ
AC 100-240 V, 50/60 Hz
1.60 - 0.75 A
Landscape: 611.8 mm (W) x 378.0 - 528.0 mm (H) x 250.0 mm (D)
24.1 inches (W) x 14.9 - 20.8 inches (H) x 9.8 inches (D)
Portrait: 361.9 mm (W) x 628.6 - 652.1 mm (H) x 250.0 mm (D)
14.2 inches (W) x 24.7 - 25.7 inches (H) x 9.8 inches (D)
150 mm/5.9 inches (Landscape orientation)
23.5 mm/0.9 inches (Portrait orientation)
Up 35° Down 5° / ± 90° / 340°
9.5 kg (20.9 lbs)/Without stand: 6.1 kg (13.4 lbs)
5°C to 35°C/41°F to 95°F
Humidity: 20% to 80%
Altitude: 0 to 16,404 Feet/0 to 5,000 m
-10°C to 60°C/14°F to 140°F
Humidity: 10% to 85%
Altitude: 0 to 40,000 Feet/0 to 12,192 m
Notes
Active matrix; thin film transistor (TFT) liquid crystal
display (LCD); 0.155 mm dot pitch; 350 cd/m
luminance; 1300:1 contrast ratio (typical), (9000:1
Contrast ratio, Dynamic).
DisplayPort V1.2 (HDCP1.3)
DisplayPort V1.2 (HDCP1.3)
HDMI2 (HDCP1.4), HDMI1 (HDCP2.2)
Depends on display card used.
Automatically
Automatically
Upstream port applicable to USB monitor control.
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Impedance 32 Ohm
English-23
