Controls

OSD (On-Screen Display) control keys on the front of the monitor function
as follows:
1 Ambient Light Sensor
Human Sensor
2 INPUT/SELECT
3 MENU/EXIT
4 LEFT/RIGHT/
UP/DOWN* 2
5 /RESET
6 Power
7 Power LED
* 1 When the Hot Key function is OFF, this function is disabled.
* Depending on the OSD ROTATION setting, LEFT, RIGHT, UP and DOWN key guides are displayed at the , ,
2
differently (See page 19).
* MULTI PICTURE menu.
3
Touch the LEFT/RIGHT to select a priority (adjustable) screen. When MULTI PICTURE is OFF, a single screen will be
displayed.
* Swapping of Picture-By-Picture is not supported. The sound keeps the value of SOUND INPUT setting.
4
The expansion keeps the values of EXPANSION setting of each input.
Detects the level of ambient lighting and the presence of a user, allowing the monitor to
make adjustments to various settings resulting in a more comfortable viewing experience.
Do not cover this sensor.
Changes the input source when the OSD menu is closed. Enters a sub-menu when the OSD
menu is open. You can directly change to L/B (LOW BLUE LIGHT) mode by touching the
INPUT key for 3 seconds or more.
Opens the OSD menu. Closes the OSD sub-menus and main menu.
Navigates through the OSD menu.
When the OSD menu is closed, touch one of the following keys to open the menu for the
function indicated:*
1
UP key: BRIGHTNESS
DOWN key: VOLUME
RIGHT key: USB SELECTION
When the OSD menu is open, this button works as a reset command for the OSD settings.
When the OSD menu is closed, this button works as a select function for the MULTI PICTURE
settings.*
3
You can swap pictures between a main screen and a sub-screen by touching the
key for 3 seconds or more while Main or Sub is set in MULTI PICTURE.*
Turns the monitor on and off.
Indicates that the power is on or off.
English-13
/RESET
*
1, 4
, keys
