Features

UHD/4K resolution: Provides more vivid and crisp images with 3860 x 2160 pixels.
USB Type-C With Power Delivery: Supports video & audio input, USB hub function and supplies power to connected devices
by a single cable, which provides flexible connectivity in a tidy work environment.
3-side Narrow Bezel: Stylish appearance and less distance between adjacent multi-screens.
Fully Ergonomic Stand: Provides viewing flexibility with 150mm height adjustment, -5 ~ 35-degree tilt, 170-degree swivel to
both right/left directions with cable management function and small footprint. Monitor head (display part) can touch the stand
base for lower position requirement.
ErgoDesign Features: Enhance human ergonomics to improve the working environment, protect the health of the user and
save money. In addition to the fully ergonomic stand, examples include OSD controls for quick and easy image adjustment and
lower emissions.
VESA Standard Mounting Interface: Connects the MultiSync monitor to any VESA standard third party mounting arm or
bracket.
OSD Rotation: Supports better intuitive OSD operation when the monitor is set in pivot (90/270 degrees) or inverted
(180 degrees).
Plug and Play: The Microsoft
solution with the Windows
operating system facilitates setup and installation by allowing
®
®
the monitor to send its capabilities (such as screen size and resolutions supported) directly to your computer, automatically
optimizing display performance.
USB Hub 3.1 Gen.1: The USB hub adds flexibility to your computing by providing easy access to USB SuperSpeed data
transfer and charging via USB. For more details, please see
page
7.
Picture-By-Picture/Picture-In-Picture: Two different input sources can simultaneously be viewed side by side (Picture-By-
Picture) or a small sub-screen on a large main screen (Picture-In-Picture), which increases job productivity.
Hardware Calibration: Adjusts brightness, colors and gamma curve for your preference with software and color sensor.
USB Monitor Control: Allows you to adjust each item through application software by connecting a USB cable.
6-Axis Color Control: In addition to RGB (Red/Green/Blue) colors, CMY (Cyan/Magenta/Yellow) colors can be adjusted for
better color reproduction such as matching print images.
Uniformity (UNIFORMITY): This feature compensates for slight variations in the white uniformity level that may occur on the
screen and improves the color and evens out the luminance uniformity of the display.
Human/Ambient Sensors: Controls screen brightness according to user presence and ambient light status for less power
consumption.
Response Improve (RESPONSE IMPROVE): Improves gray to gray response.
Intelligent Power Manager System: Provides innovative power-saving methods that allow the monitor to shift to a lower power
consumption level when on but not in use, saving two-thirds of your monitor energy costs, reducing emissions and lowering the
air conditioning costs of the workplace.
ControlSync: Provides control and synchronization of settings for up to eight MultiSync EA series displays from a single master
monitor (see
page
11).
Individual Adjust (INDIVIDUAL ADJUST): A designated main monitor can adjust an individual sub-monitor(s) by the OSD. It is
good for multi-setting monitors which are positioned far from the user.
180-Degree Image Rotation: When multiple monitors are set in a vertical direction, for optimizing narrower bezel of the top
side, upper monitors can be inverted. This function can correct the screen rotation image without using an OS function, which
supports, for example, easier Tile Matrix setting.
Customize Setting (CUSTOMIZE SETTING): Allows to store the current settings and recover stored settings.
Low Blue Light: Low Blue Light function substantially reduces blue light and helps to alleviate eye-strain (see
page
22).
Flicker Free: Special backlight system reduces flicker for less eyestrain.
NaViSet Administrator 2 Software: Offers an expanded and intuitive graphical interface, allowing you to more easily adjust
OSD display settings from network PC.
Environmental Impact: Annual typical maximum operating carbon footprint of this monitor (world-wide average) is
approximately 136.4 kg (calculated by: rated wattage x 8 hours per day x 5 days a week x 45 weeks per year x Power-to-
Carbon conversion factor - conversion factor is based on OECD publication of global CO2 emissions 2008 Edition). This monitor
has a manufacturing carbon footprint of approximately 63.0 kg.
Note: The manufacturing and operating carbon footprints are calculated by a unique algorithm developed exclusively by NEC
for its monitors and are accurate at the time of printing. NEC reserves the right to publish updated carbon footprint values.
English-25
