DK321 Rhino-Rack VA, Aero, Euro & HD
Vehicle
Date
Crossbar
Toyota Camry
2012-
1180mm
50R 4dr sedan
Toyota Aurion
2012-
1180mm
50R 4dr sedan
IDENTIFICATION CHART
FRONT CROSSBAR
VA
Front
Front
Measurement
Right
Left
strip length
Pad/
Pad/
per side
Clamp
Clamp
M282
M281
SUB0372
SUB0372
173mm
Arrow
FORWARD
M282
M281
SUB0372
SUB0372
173mm
Arrow
FORWARD
crossbar
instruction
Identification
VA crossbar
AERO crossbar
AERO
HD
EURO
Measurement
Measurement
Foot plate
strip length
Distance
arrow
per side
( x )
direction
914mm /
118mm
OUT
35,63/64"
914mm /
118mm
OUT
35,63/64"
EURO crossbar
REAR CROSSBAR
VA
Rear
Rear
Measurement
Measurement
Right
Left
strip length
strip length
Pad/
Pad/
per side
per side
Clamp
Clamp
M527
M528
SUB0373
SUB0373
155mm
100mm
Arrow
FORWARD
M527
M528
SUB0373
SUB0373
155mm
100mm
Arrow
FORWARD
HD crossbar
AERO
HD
EURO
Measurement
Foot plate
Distance
arrow
( x )
direction
878mm /
OUT
34,9/16"
878mm /
OUT
34,9/16"
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Rhino-Rack DK321 VA
Summary of Contents for Rhino-Rack DK321 VA
- Page 1 DK321 Rhino-Rack VA, Aero, Euro & HD crossbar instruction Identification IDENTIFICATION CHART VA crossbar AERO crossbar EURO crossbar HD crossbar FRONT CROSSBAR REAR CROSSBAR AERO AERO EURO EURO Front Front Rear Rear Measurement Measurement Measurement Foot plate Measurement Measurement Measurement...
- Page 2 DK321 Rhino-Rack VA, Aero, Euro & HD crossbar instruction Measurement A: CENTRE of door jamb to CENTRE arrow of leg foot plate. Measurement B: CENTRE of Front leg foot plate arrow to CENTRE of Rear leg foot plate arrow. Carrying capacity: Roof rack is rated to 75kg. Please refer to manufacturers handbook for your vehicles maximum roof load capacity. Always use the lower of the two figures.
