Equipment
connected equipment
Audio equipment
audio output
RCA audio
Monitor
Amplifi er
audio input
RCA audio
Note
• You can also use the MONITOR OUT terminal as the COMPUTER/COMPONENT 2 terminal. To use
this terminal as an output terminal, set "COMPUTER2 Select" to "Monitor Output" before connecting
the external equipment. (See page 52.)
• When using the ø3.5 mm mono audio cable, the volume level will be half of when using the ø3.5 mm
stereo audio cable.
• You can select AUDIO 1 or AUDIO 2 in the INPUT list. (See page 30.)
• RGB signals and Component signals can be output to the monitor.
Terminal on
ø3.5 mm ø3.5 mm stereo or mono audio cable
(commercially available or available
terminal as Sharp service part QCNWGA038WJPZ)
RCA audio cable (commercially available)
output
terminal
Cables for a camera or a video game
Audio
output
terminal
RGB RGB cable (supplied or commercially
input available)
terminal
ø3.5 mm stereo or mono audio cable
ø3.5 mm
(commercially available or available
as Sharp service part QCNWGA038WJPZ)
terminal
ø3.5 mm stereo minijack to RCA audio cable
(commercially available)
input
terminal
Cable
Terminal on the
projector
AUDIO 1
AUDIO 2
MONITOR OUT
AUDIO OUT
