SETUP MANUAL
Connecting Pin Assignments .............................. 2
Projector .......................................................14
Controlling the Projector via LAN ..................... 16
(Version 5.0 or later)......................................16
Controlling the Projector (Control) ..........................17
(Settings & Adjustments) ..............................18
(Network - General) .....................................19
(Mail - Originator Settings) ..........................19
Telnet .......................................................... 21
When Connecting Using RS-232C .........................21
When Connecting Using Telnet ..............................22
SETUP MENU (Main Menu) ....................................23
ADVANCED SETUP MENU ....................................23
Set Items ................................................................24
DATA PROJECTOR
MODEL
PG-D3750W
IP Address Setting ([1]IP Address) .........................26
User Name Setting ([4]User Name) ........................26
Password Setting ([5]Password) .............................27
([6]RS-232C Baud Rate) ...............................27
([D]Disconnect All) ........................................28
([A]Advanced Setup) .....................................28
(ADVANCED[0]Search Port) ..........................30
via LAN ....................................................... 31
Troubleshooting .................................................. 33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PG-D3750W and is the answer not in the manual?

Questions and answers

Related Manuals for Sharp PG-D3750W

Summary of Contents for Sharp PG-D3750W

  • Page 1: Table Of Contents

    DATA PROJECTOR MODEL PG-D3750W SETUP MANUAL Connecting Pin Assignments ......2 Quit without Saving Settings ([Q]Quit Unchanged) ...25 IP Address Setting ([1]IP Address) ......26 RS-232C Specifi cations and Commands ... 4 Subnet Mask Setting ([2]Subnet Mask) ....26 Setting up the Projector Network Environment ... 10 Default Gateway Setting ([3]Default Gateway) ..26 1.

  • Page 2: Connecting Pin Assignments

    Connecting Pin Assignments COMPUTER/COMPONENT input and COMPUTER/COMPONENT output Terminals: mini D-sub 15 pin female connector COMPUTER Input/Output COMPUTER Input/Output Pin No. Signal Pin No. Signal Video input (red) PR (CR) Video input (green/sync on green) Video input (bluea) PB (CB) Not connected Not connected Not connected...
  • Page 3 Connecting Pin Assignments RS-232C Terminal: D-sub 9 pin male connector Pin No. Signal Name Reference Not connected Receive Data Input Connected to internal circuit Send Data Output Connected to internal circuit Not connected Signal Ground Connected to internal circuit Not connected Request to Send Connected to CS in internal circuit Clear to Send...

  • Page 4: Rs-232C Specifi Cations And Commands

    RS-232C Specifi cations and Commands Computer control A computer can be used to control the projector by connecting an RS-232C serial control cable (cross type, commercially available) to the projector. (See page 24 of the projector's operation manual for connection.) Communication conditions Set the serial port settings of the computer to match that of the table.
  • Page 5 RS-232C Specifi cations and Commands Commands Example: When turning on the projector, make the following setting. Compuer Projector RETURN CONTROL CONTENTS COMMAND PARAMETER Standby mode Power ON (or 30-second startup time) P O W R _ _ _ 1 OK or ERR Power P O W R _ _ _ 0 OK OK or ERR...
  • Page 6 * OK or ERR Tint -30 – +30 R A T * OK or ERR R A S H _ Sharp -30 – +30 * OK or ERR R A C T _ _ CLR Temp -1 – +1 * OK or ERR R A W E _ _ _ BrilliantColor™...
  • Page 7 * OK or ERR Tint -30 – +30 R C T * OK or ERR R C S H _ Sharp -30 – +30 * OK or ERR R C C T _ _ CLR Temp -1 – +1 * OK or ERR R C W E _ _ _ BrilliantColor™...
  • Page 8 * OK or ERR Tint -30 – +30 V B T * OK or ERR V B S H _ Sharp -30 – +30 * OK or ERR V B C T _ _ CLR Temp -1 – +1 * OK or ERR V B W E _ _ _ BrilliantColor™...
  • Page 9 RS-232C Specifi cations and Commands RETURN CONTROL CONTENTS COMMAND PARAMETER Standby mode Power ON (or 30-second startup time) I M B G _ _ _ 1 OK or ERR Background Logo I M B G _ _ _ 3 OK or ERR Blue I M B G _ _ _ 4 OK or ERR None...

  • Page 10: Setting Up The Projector Network Environment

    Setting up the Projector Network Environment This section describes the basic procedure for using the projector via the network. If the network is already constructed, the projector's network settings may need to be changed. Please consult your network administrator for assistance with these settings. You can make network settings both on the projector and on the computer.

  • Page 11: Connecting The Projector To A Computer

    Setting up the Projector Network Environment 1. Connecting the Projector to a Computer Establishing a one-to-one connection from the projector to a computer. Using a commercially available LAN cable (UTP cable, Category 5, cross-over type) you can confi gure the projector via the computer. Disconnect the computer's LAN cable from the existing network.

  • Page 12: Setting An Ip Address For The Computer

    Setting up the Projector Network Environment 2. Setting an IP Address for the Computer The following describes how to make ® settings in Windows Vista Log on the network using the administrator's account for the computer. Click “start”, and click “Control Panel”.
  • Page 13 Setting up the Projector Network Environment Click “Internet Protocol Version 4 (TCP/IPv4)”, and click the “Properties” button. Confi rm or change an IP address for the setup computer. 1 Confi rm and note the current IP address, Subnet mask and Default gateway.

  • Page 14: Setting Up A Network Connection For The Projector

    Setting up the Projector Network Environment 3. Setting up a Network Con- nection for the Projector Settings for such items as the projector's IP address and subnet mask are compatible with the existing network. Set each item on the projector as follows. (See page 50 of the projector's operation manual for setting.) DHCP Client: Off...
  • Page 15 Setting up the Projector Network Environment The TCP/IP setting screen appears, ready for network settings for the projector. Items Setting example / Remarks You can set the password to protect Password the TCP/IP setting. DHCP Select “ON” or “OFF” to determine Client whether to use DHCP Client.

  • Page 16: Controlling The Projector Via Lan

    Controlling the Projector via LAN After connecting the projector to your network, enter the projector IP address in “Address” on Internet Explorer (version 5.0 or later) using a computer on the network to start a setup screen that will enable control of the projector via the network. Controlling the Projector Using Internet Explorer (Version 5.0 or later)

  • Page 17: Confi Rming The Projector Status (Status)

    Controlling the Projector via LAN Confi rming the Projector Controlling the Projector Status (Status) (Control) On this screen, you can perform projector control. You can control the following items: • Power On this screen, you can confi rm the • Input Select projector status.

  • Page 18: Setting And Adjusting The Projector (Settings & Adjustments)

    Controlling the Projector via LAN Setting and Adjusting the Setting the Security Projector (Settings & Adjustments) (Network – Security) Example: “Picture” screen display for COMPUTER1 On these screens, you can make projector On this screen, you can make settings settings or adjustments. You can set or relating to security.

  • Page 19: Making General Settings For The Network

    Setting the projector name. mail transmission. Name e.g.1: 192.168.150.253 Auto Logout Setting the time interval in which the e.g.2: smtp123.sharp.co.jp Time projector will be automatically * When using a domain name, make disconnected from the network in units settings for the DNS server.

  • Page 20: Setting Error Items And Destination Addresses To Which E-Mail Is To Be Sent When An Error Occurs (Mail - Recipient Settings)

    Controlling the Projector via LAN Setting Error Items and Setting Error Items and the Destination Addresses to URL that are to be which E-mail is to be Sent Displayed when an Error when an Error Occurs Occurs (Service & Support – (Mail –...

  • Page 21: Setting Up The Projector Using Rs-232C Or Telnet

    Setting up the Projector Using RS-232C or Telnet Connect the projector to a computer using RS-232C or Telnet, and open the SETUP MENU on the computer to carry out various settings for the projector. Input “setup” and press the “Enter” key. When Connecting Using •...

  • Page 22: When Connecting Using Telnet

    Setting up the Projector Using RS-232C or Telnet ▼SETUP MENU When Connecting Using -----------------------------SETUP MENU---------------------------- [1]IP Address [2]Subnet Mask [3]Default Gateway Telnet [4]User Name [5]Password [6]RS-232C Baud Rate [7]Projector Name [8]DHCP Client [A]Advanced Setup [D]Disconnect All [V]View All Setting [S]Save & Quit [Q]Quit Unchanged ®...

  • Page 23: Setup Menu (Main Menu)

    Setting up the Projector Using RS-232C or Telnet SETUP MENU ADVANCED SETUP MENU (Main Menu) ▼SETUP MENU ▼ADVANCED SETUP MENU ********************** ADVANCED SETUP MENU *************************** -----------------------------SETUP MENU---------------------------- [1]Auto Logout Time [2]Data Port [1]IP Address [2]Subnet Mask [3]Default Gateway [5]Network Ping Test [4]User Name [5]Password [6]Accept IP Addr(1)

  • Page 24: View Setting Detail List ([V]View All Setting)

    Setting up the Projector Using RS-232C or Telnet Enter number or symbol of item to be selected on the SETUP MENU. When setting, input the details to be set. Setting is carried out one item at a time, and saved at the end. View Setting Detail List Set Items ([V]View All Setting)

  • Page 25: Save Settings And Quit ([S]Save & Quit)

    Setting up the Projector Using RS-232C or Telnet Save Settings and Quit Quit without Saving Set- tings ([S]Save & Quit) ([Q]Quit Unchanged) Save set values and quit menu. Quit menu without saving setting values. ▼SETUP MENU ▼SETUP MENU ----------------------------SETUP MENU--------------------------- ----------------------------SETUP MENU--------------------------- [1]IP Address [2]Subnet Mask...

  • Page 26: Ip Address Setting ([1]Ip Address)

    Setting up the Projector Using RS-232C or Telnet The setting procedure for each item will be explained. For the basic procedure, please refer to “Set Items” on page 24. IP Address Setting Default Gateway Setting ([1]IP Address) ([3]Default Gateway) Setting of IP address. Setting default gateway.

  • Page 27: Password Setting ([5]Password)

    Setting up the Projector Using RS-232C or Telnet Password Setting Projector Name Setting ([5]Password) ([7]Projector Name) Carrying out security protection using It is possible to assign a projector name. password. setup>7 Projector Name : XX-XXXX setup>5 Please Enter : MY XX-XXXX Password (change) —>...

  • Page 28: Disconnecting All Connections

    Setting up the Projector Using RS-232C or Telnet Disconnecting All Connec- Setting Auto Logout Time tions ([D]Disconnect All) (ADVANCED[1]Auto Logout Time) It is possible to disconnect all the TCP/IP If there is no input after a fi xed time, the connections currently recognized by the projector automatically disconnects network projector.

  • Page 29: Carrying Out Network Ping Test

    Setting up the Projector Using RS-232C or Telnet Carrying out Network Ping Setting of Accept IP Ad- Test dress (ADVANCED[6]Accept IP (ADVANCED[5]Network Ping Test) Addr(1) - [8]Accept IP Addr(3)) It is possible to confi rm that a network It is possible to improve security of the connection between the projector and a projector by allowing connection from only a computer etc.

  • Page 30: Setting Of Search Port

    Setting up the Projector Using RS-232C or Telnet Setting of Search Port Return to Main Menu (ADVANCED[0]Search Port) (ADVANCED[Q]Return to Main Menu) Sets the port number used when searching for the projector from the network. Returns to the main SETUP MENU. advanced>0 advanced>q Please Enter Port Number for Search from Computer.

  • Page 31: Resetting The Lamp Timer Of The Projector Via Lan

    Resetting the Lamp Timer of the Projector via LAN When the projector is connected to a network, you can use the communications program to send a command to reset the lamp timer. The example below uses Windows ® XP as the ®...
  • Page 32 Resetting the Lamp Timer of the Projector via LAN Click “Properties” on the “File” menu. Click the “Settings” tab, and then click “ASCII Setup”. Select the check boxes next to “Send line ends with line feeds”, “Echo typed characters locally”, and “Append line feeds to incoming line ends”, and click “OK”.

  • Page 33: Troubleshooting

    Troubleshooting Communication cannot be established with the projector When connecting the projector using serial-connection Check that the RS-232C terminal of the projector and a computer or the commercially available controller are connected correctly. Check that the RS-232C cable is a cross-over cable. Check that the RS-232C port setting for the projector corresponds to the setting for the computer or the commercially available controller.
  • Page 34 Troubleshooting Take the following steps for checking the network settings for the computer. 1. Open a command prompt. 2000: click “start” ➔ “Programs” ➔ “Accessories” • In the case of Windows ® ➔ “Command Prompt” in order. : click “start” ➔ “All Programs” •...
  • Page 35 Troubleshooting Check if the “TCP/IP” protocol is operating correctly using the “PING” command. Also, check if an IP address is set. 1. Open a command prompt. 2000: click “start” ➔ “Programs” ➔ “Accessories” ➔ ® • In the case of Windows “Command Prompt”...
