Sharp PG-D3550W Specifications

PG-D3550W/D3050W/D2870W
The PG-D3550W, PG-D3050W and PG-D2870W are identical in front, top and side cabinet appearance
with the exception of the model number indication and the PG-D2870W lens appearance.
Optional Accessories
Lamp USB Remote Cable Ceiling Mounts
Receiver
AN-C3CP2
3-RCA to 15-pin
AN-TK201
D-sub cable
AN-D350LP AN-MR2 (10' (3 m)) For high ceiling installation
Note: Some of the optional accessories may not be available depending on the region.
3D Signal Compatibility
Please check with your nearest Sharp Authorized Projector Dealer or Service Center.
Horizontal frequency Vertical frequency
Signal Analog Support
[kHz] [Hz]
37.9 60
SVGA 800 x 600
77.1 120
48.4 60
XGA 1,024 x 768
98.6 120
49.7 60
1,280 x 800
101.6 120* 1
WXGA
45.0 60
1,280 x 720
92.6 120
*1 Reduced blanking
Specifications
Models
Display devices
Resolution
Brightness 3,500 lumens
Contrast ratio
Lens F number
Zoom
Focus
Picture size
Projection distance
Input signals Computer RGB
DTV
Input terminals HDMI
Computer / Component (mini D-sub 15-pin)
S-Video (mini DIN 4-pin)
Video (RCA)
Audio (ø3.5-mm stereo minijack)
Audio (RCA)
Output terminals Computer / Component (mini D-sub 15-pin)
Audio (ø3.5-mm stereo minijack)
LAN (RJ-45)
Control and
communication USB (Type B)
terminals
RS-232C (mini D-sub 9-pin)
Horizontal frequency
Vertical frequency
Audio system
Fan noise
Projection lamp
Lamp life
On-screen display languages English, German, Spanish, Dutch, French, Italian, Swedish, Portuguese, Russian, Polish, Hungarian, Turkish, Arabic, Persian, simplified Chinese, Korean, Japanese
Rated voltage
Rated frequency
Input current
Power consumption Eco + Quiet Off
Eco + Quiet On
Standby mode Quick Start
Eco
Operation temperature
Cabinet
Dimensions (main body only) W x H x D
Weight (approx.)
Supplied accessories Remote control, Two R-6 batteries, Power cord (6' (1.8 m)), RGB cable (10' (3.0 m)), Operation manual, CD-ROM, DIN D-sub RS-232C adaptor, Storage case
Design and specifications are current as of June 2010, but are subject to change without notice. *1 Compatible in intelligent compression
• Crestron is a registered trademark of Crestron Electronics, Inc. • AMX is a registered trademark of AMX Corporation.
• PJLink is a registered trademark or an application trademark in Japan, the United States, Canada, the E.U., China and other countries or regions.
warranties or representations of any kind with respect to these products. • The lamp life may vary depending on the usage condition.
SHARP CORPORATION
OSAKA, JAPAN
Dimensions (PG-D3550W/D3050W/D2870W)
Top Back
Front
The dimensions of the PG-D3550W, PG-D3050W and
PG-D2870W are identical, but the PG-D2870W lens
appearance is different.
2 61 / 64 (75)
52
11 / 64 (300)
Rear terminals
AN-TK202
For standard
ceiling installation
AN-60KT
Installation PG-D3550X/D3050X/D2870W
adaptor
Precautions on Viewing Stereoscopic 3D
Digital Support
• The sense of three-dimensionality may vary between individuals.
• Viewing stereoscopic 3D may cause discomfort or eye strain.
• For protection of proper eye development, children should avoid viewing stereoscopic 3D.
• Avoid viewing stereoscopic 3D if you have a pre-existing oversensitivity to light, sleep disorder, heart disease, or are
pregnant, in poor health, feeling unwell, or inebriated.
• Read the operation manual carefully to ensure viewing stereoscopic 3D with safety and comfort.
0.65" DLP ® chip x 1
WXGA (1,280 x 800)
3,000 lumens
2,000:1
F 2.4 to 2.6
Manual, x 1.20 (f = 19.0 to 22.7 mm)
Manual
40" (102 cm) to 300" (762 cm) 60" (152 cm) to 150" (381 cm)
100" : 2.9 – 3.6 m
UXGA* 1 / SXGA+* 1 / SXGA* 1 / WXGA / XGA / SVGA / VGA
Mac 21"* 1 / 19" / 16" / 13"
1080P / 1080I / 720P / 576P / 576I / 540P / 480P / 480I
NTSC / PAL / SECAM
1
2
1
1
1
1 (L/R)
1 (Shared with computer / component input 2, switchable)
1 (variable audio output)
1
1
1
15 to 110 kHz
45 to 85 Hz
7 W (mono)
38 dB (Eco+Quiet Off), 30 dB (Eco+Quiet On)
250 W
5,000 hours (Eco+Quiet)
AC100 to 240 V
50 / 60 Hz
3.2 A
322 W with AC 100 V, 309 W with AC 240 V
215 W with AC 100 V, 210 W with AC 240 V
4.4 W with AC 100 V, 5.2 W with AC 240 V
0.32 W with AC 100 V, 0.77 W with AC 240 V
41°F to 95°F (+5°C to +35°C)
Plastic
300 x 79 x 236 mm
2.8 kg
• DLP , the DLP logo, BrilliantColor™ and DLP Link™ are trademarks or registered trademarks of Texas Instruments.
® ®
• HDMI, the HDMI logo and High Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC.
• All company and product names are trademarks or registered trademarks of their respective manufacturers. Sharp makes no
• Brightness values indicate overall average values of the product at the time of shipment and are stated based on ISO 21118-2005.
© SHARP CORP. (JUN. 2010 PRINT) I E
1 31 / (50)
32
M4 M4
M4 M4
1 9 / 32 (32.5)
2 61 / (75)
64
5 27 / (137.5) 4 21 / (118)
64 32
Units: inches (mm)
F 2.8
No zoom (f = 10.2 mm)
100" : 1.5 m
New Sharp 3D-ready projectors with WXGA resolution and
high brightness deliver dynamic performance and image
quality to meet an expanded range of viewer applications.
2.9 kg
True WXGA Data Projectors
Short-Throw True WXGA Data Projector
PG-D3550W
