Image Projection

About the Setup Guide

After turning on the projector, the Setup
Guide screen appears to assist you with
projector setup.
Guidance items
1 FOCUS
2 HEIGHT ADJUST
3 ZOOM
Press ENTER to exit the Setup Guide
screen.
Note
• The Setup Guide screen automatically
highlights the items in the following order:
1 FOCUS
4 ENTER
However, you can adjust the focus or height
(angle) regardless of the highlighted item.
• If you do not want to display the Setup Guide
for the next time, set "Menu" - "SCR - ADJ" -
"Setup Guide" to "Off". (See page 48.)

Adjusting the Projected Image

1 Adjusting the Focus
You can adjust the focus with the focus
ring on the projector.
Rotate the focus ring to adjust the
focus while watching the projected
image.
• Using the knob on the focus ring will make the
adjustments easier.
26
2 HEIGHT ADJUST
3 ZOOM
Setup Guide screen
Focus ring
ENTER button
