Installation and
Maintenance Instructions
Combi Screw and
Roots Vacuum Pumps
COBRA BC 0600 F
Standard version
Busch Manufacturing Korea, Ltd.
189-51, Soicheon-ro, Majang-myun
Icheon-si, Gyunggi-do, 467-813
Republic of Korea
0870767449/
181024 / Original instructions / Subject to change without notice
Advertisement
Table of Contents
Related Manuals for BUSCH COBRA BC 0600 F
Summary of Contents for BUSCH COBRA BC 0600 F
- Page 1 Installation and Maintenance Instructions Combi Screw and Roots Vacuum Pumps COBRA BC 0600 F Standard version Busch Manufacturing Korea, Ltd. 189-51, Soicheon-ro, Majang-myun Icheon-si, Gyunggi-do, 467-813 Republic of Korea 0870767449/ 181024 / Original instructions / Subject to change without notice...
-
Page 2: Table Of Contents
Lock Out/ Tag Out procedure ....17 COBRA BC 0600 F ..... 3 Safety Lockout procedure. -
Page 3: Cobra Bc 0600 F
COBRA BC 0600 F OSG1 IN Inlet connection OUT Discharge connection OFP Oil fill plug OSG 1 Oil sight glass ODP Oil drain plug CWC Cooling water connections NC Nitrogen connections CP PLC box EB Eyebolts CPC PLC connection ES Emergency stop button (EMO) - Page 4 OSG4 MOT2 DGR2 OSG1 DGR1 PSA CWM CWR MOT1 BC 0600 F Page 4 0870767449 (En)
- Page 5 On/ off switch/ Main circuit breaker PWS DC Power Supply Current Transducer Circuit breaker BC 0600 F Page 5 0870767449 (En)
-
Page 6: Product Description
COMBI All product-specific safety regulations must be observed. The COBRA BC 0600 F pumps are a combination of a screw vacuum Solid particles must not get into the vacuum pump. Procedural errors pump NW 0100 E (DP) and a Roots vacuum pump WY 0700 C (MB) can result in the pump sucking in a certain quantity of liquid. -
Page 7: Principle Of Dp Vacuum Pumps
Example: BC 0600 F BC = standard version NOTE: The COBRA BC 0600 F vacuum pumps are principally dispat- 0600 = 600 m ched without oil already in the vacuum pump but, without cooling wa- F = Design ter. -
Page 8: Safety
It is vital that these installation and maintenance instructions are read and understood before the vacuum pump is used. If you have any doubts, please contact your local Busch representative. Safety information The vacuum pump has been designed and manufactured in accordance with the latest technical and safety standards. -
Page 9: Noise Emission
Noise emission Installation of the vacuum pump in a seismic zone Refer to the table “Technical data” for the permissible noise leveling free field conditions according to EN ISO 2151. Upon receipt, the vacuum pump is fixed on the transport pallet with two brackets. -
Page 10: Information Over The Lubricants
Information over the lubricants Busch YLC 250 B, Art. No. 0831 000 054 (0,5 l @ 1 kg) Quantity BC 0600 F: WY 0700 C-MB: 1,4 l – NW 0100 E-DP: 0,12 l – Replacement: After 16'000 h (see Maintenance program) Technical data sheet: Please refer to chapter "Oil type/ Quantity". -
Page 11: Start-Up Of The Vacuum Pump After Storage
NOTE: VCI is the abbreviation for “volatile corrosion inhibitor”. The NOTE: 1° (german degree = 1° dGH) = 1,78° (french degree) = 1,25 e VCI molecule is an organic corrosion inhibitor in the vapour phase. (english degree) = 17,9 mg/kg CaCO3 (american hardness) Integrated in various carriers such as film, cardboard, paper, foam, li- –... -
Page 12: Discharge Connection
In the case of long discharge lines the line cross-section should be lar- ger than the discharge flange to prevent a drop in the performance of the vacuum pump. If you have any doubts, contact your Busch repre- CAUTION sentative. -
Page 13: Cooling Water Connection
Ethernet network connection (Busch Monitoring System) (option) Interface connection (50 poles) (option) PID Interface (9 poles) (option) The information concerning the use of the Busch PLC and the Busch LCD can be found in the Operation and Maintenance manual (Art-No. 0870758077). BC 0600 F... -
Page 14: Connection Of The Lines/ Pipes
Make sure that the seals of the oil filler cap are not damaged. Re- The COBRA BC 0600 F vacuum pumps are generally dispatched with place them if necessary oil already in the vacuum pump. Before vacuum pump first startup, control the oil level. -
Page 15: Recommendations On Operation
Measure the working current of the motor and save it as reference value for all future maintenance and repair work CAUTION Recommendations on operation The COBRA BC 0600 F vacuum pumps could be delivered without oil, without cooling water. Application Operation without oil will result in damage to the vacuum pump! -
Page 16: Switching The System Off
Use "Automatic Load Lock" mode or "External Signal" on tool in- has been switched off and that it cannot be switched on again acciden- terface to start/stop booster (refer to Busch PLC manual). tally. Follow the shutdown procedure in the section “Lock Out/ Tag Out procedure”:... -
Page 17: Monthly
A drop in the oil level indicates a fault l Check the measuring and safety equipment for working order (see "Alarms and warnings" -> Busch PLC and Busch LCD). If the discharge is equipped with a silencer:... -
Page 18: Oil Change
If dark oil similar to the example shown is observed, you have to contact the Busch Customer Service without delay. NOTE: The quantity of oil specified in the installation handbook is of Oil change informative nature only. -
Page 19: Checking The Leak-Protection Non-Return Valve (Accessory)
Vacuum Equipment and Components”), which can be downloaded from www.buschvacuum.com. CAUTION Busch service will only accept vacuum pumps that come with a com- pletely filled in and legally binding signed form. During dismantling of the vacuum pump protective equipment and... -
Page 20: Oil Type/ Quantity
Make sure that the oil type corresponds to specification: – Busch YLC 250 B, Art. No. 0831 000 054 (0,5 l @ 1 kg) WARNING The use of chemically contaminated or polluted oil can lead to hazardous pump conditions which could cause personal injury. -
Page 21: Technical Data
Technical data Technical data BC 0600 F Effective suction capacity 50 Hz /h (cfm) 520 (305) 60 Hz /h (cfm) 620 (365) Ultimate pressure Torr 2.25 x 10 mbar 3 x 10 (50 Hz) Nominal motor rating (60 Hz) (50 Hz) Nominal motor rating (60 Hz) Electric power capacity... -
