GETTING STARTED
N
- Cancel selection
Directional - Left/Right and Up/Down
This side up.
A
Y
- Accept selection
1. Position the battery pack (as shown)
with the arrows facing up. Tilt the top
of the battery in to align the tabs,
then down to install.
2. Install the battery pack cover, (in the
same manner as above) aligning
the tabs
and screws.
A
3. Tighten the screws.
Note - Do not overtighten screws.
4. Press the Power
Note - When you connect the data cable to a
vehicle's data link connector (DLC), the
tool is powered by the vehicle.
5. Select a function (e.g. Scanner, Tools,
5
or Oil Specs and Resets).
Note - Use the battery indicator
upper right corner of the
Home screen to monitor the battery level.
6. Navigate menus and functions
using the touch screen, or the control
buttons.
button.
in the
