FEATURES
Battery Status
Indicator LED
Touch
Screen
Scope/Multimeter
Jacks
-
Ω
+
GND
2
1
10-30V
50V~/75-MAX
Power
Supply
Jack
No / Cancel
Button
Mini USB
microSD Card
Jack
Connect the AC power supply here,
to charge the battery.
Yes / Accept
Button
Directional
Buttons
Shortcut (S) Button
Default Setting: Save Screen Image
To change this setting navigate to -
Tools > Configure Shortcut Key
Power
(On/Off)
Button
Data Cable
Connector
